Sharp LC-65LE645U - Page 84

Level
Child
P/N Seq
Child P/N Specification UIT Supply Type UOM Qty Circuit Number
7 1 9LE 013010080055 RES. CF 1.0ohm 1/10W J 0603 G Assembly Pull EA 1 R63
7 1 9LE 013010091654 RES. CF 10ohm 1/16W J 0402 G Assembly Pull EA 5 RM179,RM180,RM181,RM182,RM183
7 1 9LE 013020001654 RES. CF 200ohm 1/16W J 0402 G Assembly Pull EA 1 RH24
7 1 9LE 013022091654 RES. CF 22ohm 1/16W J 0402 G Assembly Pull EA 2 R57,R58
7 1 9LE 013030031654 RES. CF 300K ohm 1/16W J 0402 G Assembly Pull EA 1 RH49
7 1 9LE 013047011654 RES. CF 4.7Kohm 1/16W J 0402 G Assembly Pull EA 22
R145,R146,R412,R416,R423,R424,R431,R432,R433,R434,R435,R
444,RA85,RA86,RH18,RH19,RH20,RH21,RH35,RS11,RV56,RV57
7 1 9LE 013047021654 RES. CF 47Kohm 1/16W J 0402 G Assembly Pull EA 2 RH62,RH71
7 1 9LE 013056031654 RES. CF 560Kohm 1/16W J 0402 G Assembly Pull EA 1 RH41
7 1 9LE 013075090055 RES. CF 75ohm1/10W J 0603 G Assembly Pull EA 2 RN1,RN2
7 1 9LE 013110011614 RES. MF 1K ohm 1/16W F 0402 G Assembly Pull EA 2 R61,R62
7 1 9LE 013122120015 RES. MF 22.1Kohm 1/10W F 0603 G Assembly Pull EA 1 RA58
7 1 9LE 013131611614 RES. MF 3.16K ohm 1/16W F 0402 G Assembly Pull EA 1 RV58
7 1 9LE 013149991614 RES. MF 49.9ohm 1/16W F 0402 G Assembly Pull EA 2 R49,R50
7 1 9LE 013162011614 RES. MF 6.2Kohm 1/16W F 0402 G Assembly Pull EA 1 R403
7 41 9LE 017122725675 PCB MAIN BD 185*141*1.6t 4L (LC-65LE645U)(1:2) G Assembly Pull EA 1
7 1 9LE 037000011493 CHIP CORE 600OHM 0.3A 0603(BLM18AG601SN1)LF G Assembly Pull EA 10
FBM10,FBM11,FBM12,FBM3,FBM4,FBM5,FBM6,FBM7,FBM8,FBM
9
7 1 9LE 037000014252 BEAD 80ohm 6A 0805 GMLB-201209-0080P-N8B HF G Assembly Pull EA 5 FBM14,FBM15,FBM16,FBM21,LA2
7 *R* 9LE 037000014282 CHIP BEAD 80ohm 6A 0805 (GB201212K800TM) LF G Assembly Pull EA 5
7 1 9LE 037000020753 BEAD 300ohm 0.2A 0603 GMLB-160808-0300A-N8 LF G Assembly Pull EA 4 FB409,FB410,FB412,FB415
7 1 9LE 039050034293 DUAL SURFACE DIODE BAV70-7-F SMD (SOT-23) L-F G Assembly Pull EA 1 DV1
7 *R* 9LE 039050073273 DUAL SURFACE DIODE BAV70 SMD SOT-23 HF G Assembly Pull EA 1
7 1 9LE 040005415012 ZENER 5.49~5.73V UDZSTE-175.6B 1/5W SOD-323 G Assembly Pull EA 1 ZD1
7 *R* 9LE 040005415717 ZENER 5.49~5.73V KDZ5.6VY 1/5W SOD-323 LF G Assembly Pull EA 1
7 1 9LE 041050005638 TR NPN 0.2A 40V LMBT3904LT1G SOT-23 HF G Assembly Pull EA 1 QH13
7 *R* 9LE 041050005643 TR NPN 0.2A 40V METR3904-G SOT-23 HF G Assembly Pull EA 1
7 1 9LE 043000016609 IC CMOS LOGIC 74HC4052PW TSSOP 16PIN LF G Assembly Pull EA 1 UH4
7 *R* 9LE 043000038686 IC CMOS ANALOG U74HC4052G-P16-R TSSOP-16 HF G Assembly Pull EA 1
7 1 9LE 043030409688 IC EEPROM 2K K24C02-SIRXA SOP-8 HF G Assembly Pull EA 1 UM3
7 *R* 9LE 043030426034 IC EEPROM 2K BR24G02FJ-3GTE2 SOP-J8 HF G Assembly Pull EA 1
*** END ***
Confidential-do not copy
Page 14-13
File No. SG-0000313
