LC-70UD1U
9
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[5] SUPPLIED ACCESSORIES/PACKING PARTS
X1 CDAI-A899WJ03 BY N X Stand Base Ass'y
X2 CANGKD781WJ04 BC N J Stand Support Ass'y
X3 CSAKKA016WJ03 AF N X Stand Screw Ass'y
X4 KOPTLA006WJQZ BE X 3D Glasses, x2
X5 RRMCGB105WJSA AP N X Remote Control
X6 TCADEA290WJZZ AA X Enquete Card
X7 Not Available - - AA Live Card
X8 TINS-F777WJZZ AB N X 3D Glasses Manual
X9 TINS-F940WJZZ AH N X Instruction
X10 TMAN-A050WJN1 AB N X Connection Guide
X11 Not Available - - AAA size battery
S1 SPAKAA727WJZZ - - Edge Board (Top), x4 (NOT REPLACEMENT ITEM)
S2 SPAKAA738WJZZ - N - Edge Board (Bottom), x4 (NOT REPLACEMENT ITEM)
S3 SPAKCH317WJZZ - N - Packing Case (NOT REPLACEMENT ITEM)
S4 SPAKCH318WJZZ - N - Packing Case (Bottom) (NOT REPLACEMENT ITEM)
S5 SPAKPB733WJZZ - - Polyethylene bag (Main) (NOT REPLACEMENT ITEM)
S6 SPAKXE096WJZZ - N - Packing Form (Top) (NOT REPLACEMENT ITEM)
S7 SPAKXE097WJZZ - N - Packing Form (Bottom/Side) (NOT REPLACEMENT ITEM)
S8 SSAKA0101GJZZ - - Polyethylene bag (NOT REPLACEMENT ITEM)
S9 TLABKA009WJZZ - - Case No. Label (NOT REPLACEMENT ITEM)
[6] SERVICE JIG (USE FOR SERVICING)
N QCNW-L214WJQZ AV J Connecting Cord L=1000mm 64pins, LCD Control Unit to LCD Panel Unit, x4
N QCNW-F676WJQZ BH J
Connecting Cord L=1000mm 41pins, Main to DRC Unit (LW),DRC Unit to CTL Unit(FA),
x2
N QCNW-M539WJQZ BC J Connecting Cord L=1000mm 24-24/4pins, Power-Main (PD)
N QCNW-L519WJQZ BA J Connecting Cord L=1000mm 18pins, LED DRIVE to Power (LA)
N QCNW-N299WJPZ J Connecting Cord L=1000mm 12-7/5pins, Power-DRC Unit (PQ)
N QCNW-N670WJZZ J Connecting Cord L=1000mm 51pins, DRC Unit to CTL Unit (FB)
N QCNW-N671WJZZ J Connecting Cord L=1000mm 13-8pins, Power-LCD Control Unit (PF)
To Next Page
