PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-70UD1U
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL UNIT
[3] CABINET AND MECHANICAL
PARTS
[4] CABINET AND MECHANICAL
PARTS-2
[5] SUPPLIED ACCESSORIES/
PACKING PARTS
[6] SERVICE JIG
(USE FOR SERVICING)
CONTENTS
No. S83C2LC70UD1U
LC-70UD1U
MODEL
LCD COLOR TELEVISION
