US
40
<Commands for ID control>
The command examples shown on this page assume the following connection and ID number set
up.
PC ID number: 1 ID number: 2 ID number: 3 ID number: 4
IDST······A monitor receiving this command sets its own ID number in the parameter field.
Example: IDST0001
OK
001 ←The ID number of this monitor is set to 1.
Note
After linking monitors, you can automatically assign ID numbers by using the IDST command with
the Repeater control (see Repeater control on page 42).
PC Set 1 Set 2 Set 3 Set 4
[Example]
If you connect monitors as shown above, and use the command IDST001+, ID numbers
will be set automatically, as shown below.
PC ID number: 1 ID number: 2 ID number: 3 ID number: 4
[Example]
IDST001+ ID setting command with repeater control
WAIT
OK
001 ID = OK response from ID number=1
OK
002 ID = OK response from ID number=2
OK
003 ID = OK response from ID number=3
OK
004 ID = OK response from ID number=4 (End)
PC Operation (Continued)
