Chapter 13 Spare Parts List
PART NO DESCRIPTION LOC QTY REMARK
9LE018467510083
POLYSWITCH 0.75A 8V SMD (1206L075THYR) HF FU5 1
9LE018467510084
POLYSWITCH 0.75A 8V SMD (KMC3S075RY006) HF FU5 1
9LE028024000313
X'TAL 24MHZ 49S 20PF 30PPM -40~85'C LF Y1,Y2 2
9LE03351006AF52
SPK 10W 6ohm (1150*650mm) +AL FPTW for LC-65 &
LC55
1
9LE032040000470
POWER CORD 2P POLA. 1500mm 7A
UL/CSA(SP-12/IS-08A) N.M(SH)
1
9LE030064000070
OPTO CONN. Transmitter (JST1221) L-F PA1 1
9LE039050034293
DUAL SURFACE DIODE BAV70-7-F SMD (SOT-23)
L-F
DA1,DA5,DV1
3
9LE039060050293
Schottky Diode 0.2A 30V BAT54C-7-F SOT-23 HF DV2 1
9LE041050005638
TR NPN 0.2A 40V LMBT3904LT1G SOT-23 HF QA1,QA3,QA4,QH8,QH9,QI2,
QL1,QM3,QP10
9
9LE042020058629
MOSFET P-CH 3.7A 30V AP2309GN SOT-23 3PIN LF QP4 1
9LE042020073636
MOSFET P-CH 9.5A 30V SSG4835P SOP 8PIN LF UL2 1
9LE042020092643
MOSFET P-CH 3.2A 30V ME2303-G SOT-23 HF QP4 1
9LE043000016609
IC CMOS LOGIC 74HC4052PW TSSOP 16PIN LF UH4 1
9LE043000047015
IC CMOS CD74HC4094M96 SOIC-16 LF U2,U3 2
9LE043030149045
IC SERIAL FLASH 8M MX25L8006EM2I-12G SOP-8 LF UM2 1
9LE043030163045
IC SERIAL FLASH 32M MX25L3206EM2I-12G SOP-8 LF US4 1
9LE043050318985
IC MEMC MST7438BB EPLQFP-128 HF UM1 1
9LE043060270079
IC LDO 1A ADJ AP1117EG-13 SOT223-3L 3PIN HF UP3,UP4 2
9LE043060437039
IC STEP-DOWN CONV 1.5A 6V LA8013ACD SOT-23-5
LF
UP15,UP16,UP18,UP19
4
9LE043060440015
IC STEP-DOWN CONV 5A 28V TPS54531DDAR
SOIC-8 PowerPAD HF
UP2
1
9LE043070865615
IC AUDIO OP DRV632PWR TSSOP-14 HF UA2 1
9LE043070921721
IC AUDIO DSP NPCA110DA0YX QFN-32 LF UW1 1
9LE043070942715
IC AUDIO POWER AMP 20W TAS5707LPHPR
HTQFP-48 HF
UA1
1
9LE043070956079
IC RESET 4.38V APX810-44SAG-7 SOT-23 HF US1 1
9LE043071043079
IC POWER SWITCH 2.1A AP2191WG-7 SOT-23-5 HF UH3 1
9LE043140020999
IC SCALER MSD8220LBP W/O DDP EPLQFP-156 HF U1 1
9LE0430604260C1
IC STEP-DOWN CONV 3A 23V FR9889SPCTR SOP-8
LF
UP17
1
