Chapter 14 Complete Parts List
LCD TV 65'' SHARP LC-65LE541U_FPTW (AUO T650HVN05.5)
Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
1 1 9LE 366500220334 BASE ASS'Y LC-65LE643U P Phantom EA 1
2 41 9LE 170105522010 BASE(ABS 94-HB/T52013)(LC-65LE643U) G Assembly Pull EA 1
2 31 9LE 172130030620 TAP. SCREW-TF #3.0*6.0L,Ni G Assembly Pull EA 12
2 61 9LE 172550040720 MAC. SCREW MI M4.0*7.0L, Ni Nylok G Assembly Pull EA 12
2 81 9LE 181304014010 BASE BKT(SGCC 2.0t)(LC-65LE643U)ASS'Y G Assembly Pull EA 1
3 1 9LE 170110000700 BASE FOOT (SILICON RUBBER/ D18.0*2.0t)(447C) G Supplier EA 8
3 1 9LE 171304014010 BASE BKT(SGCC 2.0t)(LC-65LE643U) G Supplier EA 1
2 91 9LE 181304015011 NECK BKT(SGCC 1.6t)(LC-65LE643U)ASS'Y G Assembly Pull EA 2
3 1 9LE 171201027880 NECK INNER(SGCC 2.0t)(LC-65LE643U) G Supplier EA 1
3 1 9LE 171201027890 NECK SUPPORT BKT(SGCC 2.0t)(LC-65LE643U) G Supplier EA 2
3 1 9LE 171304015010 NECK BKT(SGCC 1.6t)(LC-65LE643U) G Supplier EA 1
3 1 9LE 172500040650 MAC SCREW-MB M4.0*6.0L,BLK_Ni, NYLOK G Supplier EA 2
3 1 9LE 172530040620 MAC. SCREW-MF M4.0*6.0L,NI,NYLOK G Supplier EA 4
1 1 9LE 366500420315 MRO ASS'Y LC-65LE541U_MX P Phantom EA 1
2 1 9LE 192519000860 TIE BAND(PP/L1600m*W12mm*0.7t)(WHITE) G Assembly Pull MZ 2.229
2 1 9LE 192521001740 CORNER BAR(L2000*50*50*5t) G Assembly Pull EA .333
2 1 9LE 192521003440 SLIP SHEET(L1140*W1760*0.9t/OPEN SIDE 1140) G Assembly Pull EA .084
2 1 9LE 192521003450 PAPER SHEET(L1700*W1100*8t) G Assembly Pull EA .084
2 1 9LE 193612000020 FG SHIPPING LBL(#80 art paper)(10cm x 18cm) G Assembly Pull EA .1667
2 1 9LE 193612000030 SHIPPING LBL(#80 art paper)(11cm x 7.5cm) G Assembly Pull EA .0834
2 1 9LE 193613002420 S/N LBL(#80 art paper)(55x15mm) G Assembly Pull EA 1
2 1 9LE 194712008460 CARTON TAPE(L600m*W72mm*0.06t) G Assembly Pull MZ 1.94
2 1 9LE 194725000660 PACKING FILM(L2000m*W500mm*0.0155t) G Assembly Pull MZ 3.762
1 1 9LE 366501820312 PACKING ASS'Y LC-65LE541U_MX P Phantom EA 1
2 1 9LE 192510017100 EPS FOAM_TL(LC-65LE643U) G Assembly Pull EA 1
2 1 9LE 192510017110 EPS FOAM_TR(LC-65LE643U) G Assembly Pull EA 1
2 1 9LE 192510017120 EPS FOAM_BL(LC-65LE643U) G Assembly Pull EA 1
2 1 9LE 192510017130 EPS FOAM_BR(LC-65LE643U) G Assembly Pull EA 1
2 1 9LE 192510017320 EPS FOAM FRONT(LC-65LE643U) G Assembly Pull EA 1
2 1 9LE 192511004980 EPE BAG(W1650*L1000*0.3t)(LC-65LE643U) G Assembly Pull EA 1
2 1 9LE 192511004990 PE BAG(W700*L500*0.06t)(LC-65LE643U) G Assembly Pull EA 1
2 1 9LE 192512023290 CARTON TRAY(W1712*H180*D170)(LC-65LE643U) G Assembly Pull EA 1
2 1 9LE 192512023580 CARTON(AB/FLUTE) Sharp LC-65LE541U G Assembly Pull EA 1
2 1 9LE 192517000210 CARTON JOINT(TM-32)(BLACK) G Assembly Pull EA 4
2 1 9LE 192521003620 PAPER SHEET(L395*W370*8t) G Assembly Pull EA 1
2 1 9LE 193611016910 B/C LBL(PET 50#)SHARP LC-65LE541U G Assembly Pull EA 1
2 1 9LE 193613002500 S/N LBL(Black) 40*8(PET 50#) G Assembly Pull EA 1
2 1 9LE 193614006020 CARTON LBL(art paper 80#)(50*15) Sharp G Assembly Pull EA 1
2 1 9LE 194712009090 ACETATE CLOTH TAPE(20*75*0.25t)(WHITE) G Assembly Pull EA 1
2 1 9LE 366501020393 ACCESSARY ASS'Y LC-65LE541U_MX P Phantom EA 1
3 1 9LE 032040000470 POWER CORD 2P POLA. 1500mm 7A UL/CSA(SP-12/IS-08A) N.M(SH) G Assembly Pull EA 1
3 1 9LE 060230000010 Battery Zn-Carbon 1.5V AAA(R03UG) TOSHIBA LF G Assembly Pull EA 2
3 *R* 9LE 060250000010 Battery Zn-Carbon 1.5V AAA(R03) MITSUBISHI G Assembly Pull EA 2
3 *R* 9LE 060230000040 Battery Zn-Carbon 1.5V AAA(R03UG(JE)) TOSHIBA LF G Assembly Pull EA 2
3 1 9LE 098003063200 REMOTE IR 37.9KHz 47KEY GJ221 (SHARP) LF G Assembly Pull EA 1
3 1 9LE 172500041050 MAC SCREW-MB M4.0*10.0L,BLK-Ni,NYLOK G Assembly Pull EA 4
3 1 9LE 192513015830 QSG Sharp LC-55LE541U/LC-65LE541U G Assembly Pull EA 1
3 11 9LE 194725000670 BOPP FILM(L1300m*W380mm*0.035t) G Assembly Pull MZ .3
