PC Compatibility Chart
It is necessary to set the PC correctly to display XGA and WXGA signal.
Resolution
Horizontal
Frequency
Vertical
Frequency
VESA Standard
VGA
720 x 400 31.5 kHz 70 Hz —
640 x 480
31.5 kHz 60 Hz
37.9 kHz 72 Hz
37.5 kHz 75 Hz
SVGA 800 x 600
35.1 kHz 56 Hz
37.9 kHz 60 Hz
48.1 kHz 72 Hz
46.9 kHz 75 Hz
XGA 1024 x 768
48.4 kHz 60 Hz
56.5 kHz 70 Hz
60.0 kHz 75 Hz
WXGA 1360 x 768 47.7 kHz 60 Hz
SXGA 1280 x 1024 64.0 kHz 60 Hz
SXGA+ 1400 x 1050 65.3 kHz 60 Hz
UXGA 1600 x 1200 75.0 kHz 60 Hz
1080p 1920 x 1080 67.5 kHz 60 Hz ―
2160p 3840 x 2160
53.95 kHz 24 Hz ―
*1
56.25 kHz 25 Hz ―
*1
67.5 kHz 30 Hz ―
*1
135 kHz 60 Hz ―
*2
VGA and XGA are registered trademarks of International Business Machines Corp.
*1: For the UQ/TQ/SQ/UD1U models. When connecting 4K equipment, use HDMI IN 1, 2, 3 or 4
terminal.
*2: For the UD1U only. When connecting 4K60P equipment, use HDMI IN 1, 2, 3 or 4 terminal.
NOTE
When connecting HDCP 2.2 equipment, use HDMI IN 1 terminal.
