Specifications
TV (For the UQ17U models)
Item Model: LC-80UQ17U Model: LC-70UQ17U Model: LC-60UQ17U
LCD panel
Size 80" Class (80" Diagonal) 70" Class (69 1/2" Diagonal) 60" Class (60 1/32" Diagonal)
Resolution 2,073,600 pixels (1,920 x 1,080)
TV Function
TV-standard (CCIR) American TV Standard ATSC/NTSC System
Receiving Channel
VHF/UHF VHF 2-13ch, UHF 14-69ch
CATV 1-135ch (non-scrambled channel only)
Digital Terrestrial Broadcast (8VSB) 2-69ch
Digital cable*1 (64/256 QAM) 1-135ch (non-scrambled channel only)
Audio multiplex BTSC System
Audio out 10W x 2 + 15W (WF)
Terminals
Back panel vertical side
HDMI IN 1 HDMI in with HDCP (HDCP2.2 supported)
HDMI IN 2 HDMI in with HDCP, Audio in (Ø 3.5 mm stereo jack)
HDMI IN 3 HDMI in with HDCP, ARC
HDMI IN 4 HDMI in with HDCP, MHL
AUDIO OUT Audio out (Ø 3.5 mm stereo jack)
USB 1 Photo/Music/Video mode, Software update, USB keyboard/mouse, Wallpaper Picture
Back panel surface side
COMPONENT IN COMPONENT in
VIDEO IN 1 AV in
VIDEO IN 2 AV in
PC IN
ANALOG RGB (PC) in (15-pin mini D-sub female connector),
Audio in (Ø 3.5 mm stereo jack)
RS-232C 9-pin D-sub male connector
Back panel horizontal side
ANT/CABLE
75 Unbalance, F Type x 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
AUDIO IN Audio in (Ø 3.5 mm stereo jack)
DIGITAL AUDIO OUT Optical Digital audio out x 1 (PCM/Dolby Digital/DTS)
ETHERNET Network connector
USB 2 Photo/Music/Video mode, Software update, USB keyboard/mouse, Wallpaper Picture
OSD language English/French/Spanish
Power Requirement AC 120 V, 60 Hz
On Mode Power 111 W 97 W 79 W
Power Consumption 306 W (0.1 W Standby with AC 120 V) 227 W (0.1 W Standby with AC 120 V) 187 W (0.1 W Standby with AC 120 V)
Weight
TV + stand 156.5 lbs./71.0 kg 106.9 lbs./48.5 kg 84.9 lbs./38.5 kg
TV only 135.6 lbs./61.5 kg 93.7 lbs./42.5 kg 71.7 lbs./32.5 kg
Dimensions
(W x H x D)(inch)
TV + stand 71 55/64 x 44 7/64 x 18 3/64 62 9/64 x 38 35/64 x 15 11/64 54 17/64 x 33 25/32 x 15 11/64
TV only 71 55/64 x 42 1/16 x 2 3/8 62 9/64 x 36 25/32 x 2 21/64 54 17/64 x 31 31/32 x 2 21/64
Operating temperature +32°F to +104°F (0°C to +40°C)
*1 Emergency alert messages via Cable are unreceivable.
As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures
indicated are nominal values of production units. There may be some deviations from these values in individual units.
On Mode Power Consumption is measured according to Energy Star program requirements for televisions.
ENG 12-1
