PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
MD-MT866H/MD-MT866W
R807 VRS-CZ1JB104J J AA 100 kohm,1/16W
R808 VRS-CZ1JB564J J AA 560 kohms,1/16W
R809 VRS-CZ1JB473J J AA 47 kohms,1/16W
R810 VRS-CZ1JB223J J AB 22 kohms,1/16W
R812 VRS-CZ1JB104J J AA 100 kohm,1/16W
R813 VRS-CZ1JB222J J AB 2.2 kohms,1/16W
R814 VRS-CZ1JB273J J AA 27 kohms,1/16W
R815~817 VRS-CZ1JB104J J AA 100 kohm,1/16W
R818 VRS-CZ1JB473J J AA 47 kohms,1/16W
R821 VRS-CZ1JB222J J AB 2.2 kohms,1/16W
R822 VRS-CZ1JB104J J AA 100 kohm,1/16W
R823 VRS-CZ1JB274J J AB 270 kohms,1/16W
R824 VRS-CZ1JB103J J AA 10 kohm,1/16W
R825 VRS-CZ1JB394D J AA 390 kohms,1/16W
R826 VRS-CZ1JB395J J 3.9 Mohms,1/16W
R827 VRS-CZ1JB274D J AK 270 kohms,1/16W
R828 VRS-CZ1JB222J J AB 2.2 kohms,1/16W
R829 VRS-CZ1JB104J J AA 100 kohm,1/16W
R831,832 VRS-CZ1JB184D J 180 kohms,1/16W
R833 VRS-CZ1JB470J J AB 47 ohms,1/16W
R841 VRS-CZ1JB104J J AA 100 kohm,1/16W
R844 VRS-CZ1JB470J J AB 47 ohms,1/16W
R850 VRS-CZ1JB104J J AA 100 kohm,1/16W
R853 VRS-CZ1JB274J J AB 270 kohms,1/16W
R854 VRS-CZ1JB103J J AA 10 kohm,1/16W
R855 VRS-CZ1JB184D J 180 kohms,1/16W
R857 VRS-CZ1JB564D J AA 560 kohms,1/16W
R871 VRS-CZ1JB103J J AA 10 kohm,1/16W
R881 VRS-CZ1JB183J J AA 18 kohms,1/16W
R882 VRS-CZ1JB103J J AA 10 kohm,1/16W
R904 VRS-CZ1JB103J J AA 10 kohm,1/16W
R905 VRS-CZ1JB104J J AA 100 kohm,1/16W
R906 VRS-CZ1JB274J J AB 270 kohms,1/16W
R907 VRS-CZ1JB184J J AB 180 kohms,1/16W
R908 VRS-CZ1JB104J J AA 100 kohm,1/16W
R909 VRS-CZ1JB103J J AA 10 kohm,1/16W
R920 VRS-CZ1JB104J J AA 100 kohm,1/16W
RA01 VRS-CY1JB562J J AA 5.6 kohms,1/16W
RA02 VRS-CY1JB822J J AA 8.2 kohms,1/16W
RA03 VRS-CY1JB183J J AA 18 kohms,1/16W
RA04 VRS-CY1JB563J J AA 56 kohms,1/16W
RA05 VRS-CY1JB562J J AA 5.6 kohms,1/16W
RA06 VRS-CY1JB822J J AA 8.2 kohms,1/16W
RA07 VRS-CY1JB183J J AA 18 kohms,1/16W
RA08 VRS-CY1JB563J J AA 56 kohms,1/16W
RA12 VRS-CY1JB333F J AA 33 kohms,1/16W
RA13,14 VRS-CY1JB183F J AA 18 kohms,1/16W
RA15 VRS-CY1JB564J J AA 560 kohms,1/16W
OTHER CIRCUITRY PARTS
CN101 QCNCW046XAWZZ J AM Socket,22Pin
CN451 QCNCW862PAFZZ J AG Socket,14Pin
CN601 QCNCW862LAFZZ J AF Socket,11Pin
CNA01 QCNCW047GAWZZ J AF Socket,7Pin
1 F841 QFS-L401AAFNZ J AE
Square Tip Type Fuse,0.4A,DC60V
J701 VHLGP1FD202-1 J AT Jack,Optical/Line
J702 QJAKM0018AWZZ J AG Jack,Mic In
J703 QJAKM0015AWZZ J AL
Jack,Remote Control/Headphones
M901 RMOTV0031AWZZ J AW Motor [Spindle]
M902 RMOTS0002AWZZ J AT Motor [Sled]
M903 RMOTV0033AWZZ J AW Motor [Lift]
SW401 QSW-M0010AWZZ J AE Switch,Key Type [Eject]
SW901 QSW-M0008AWZZ J AF Switch,Push Type [Lid Detection]
SWA01 QSW-K0237AFZZ J AC Switch,Key Type [Record]
SWA02 QSW-K0237AFZZ J AC Switch,Key Type [Play]
SWA03 QSW-K9023AFZZ J AD Switch,Key Type [Bass]
SWA04 QSW-K0237AFZZ J AC Switch,Key Type [Edit]
SWA05 QSW-M0009AWZZ J AE Switch,Push Type
[Volume Down]
SWA06 QSW-K0237AFZZ J AC Switch,Key Type [Display]
SWA07 QSW-M0010AWZZ J AE Switch,Push Type [Volume Up]
SWA08 QSW-K0237AFZZ J AC Switch,Key Type [Mode]
SWA09 QSW-M0010AWZZ J AE Switch,Push Type
[Fast Reverse]
SWA10 QSW-K9023AFZZ J AD Switch,Key Type [Enter]
SWA11 QSW-M0009AWZZ J AE Switch,Push Type [Fast Forward]
SWA12 QSW-K0237AFZZ J AC Switch,Key Type [Stop]
SWA13 QSW-M0010AWZZ J AE Switch,Push Type [Open]
MD MECHANISM PARTS
1 NGERH0125AWZZ J AB Wheel,Drive
2 NSFTD0007AWZZ J AL Screw,Drive
3 RCILH0003AWM1 J AT Magnetic Head Unit
1 4 RCTRH8210AFZZ J Optical Pickup
5 QPWBH0010AWZZ J AH Mechanism Flexible PWB
6 LHLDX3008AWM1 J AM Cartridge Holder Ass’y
7 MLEVF0058AWFW J AD Lift Lever
9 MSPRT0041AWFJ J AB Spring,Eject Lever
10 LANGK0211AWZZ J AC Bracket,Cancel
11 LCHSM0107AWM1 J AL Main Chassis Ass’y
12 MSPRP0044AWFJ J AB Spring,Thrust Plate
13 MLEVF0056AWFW J AC Lift Connection Lever
14 MLEVF0057AWFW J AC Lift Working Lever
15 NGERH0096AWZZ J AC Gear,Drive
16 MSPRP0043AWFJ J AB Spring,Grip
17 NBRGC0004AWZZ J AB Metal
501 LX-BZ0049AWZZ J AB Screw,ø1.4×1.8mm
502 LX-BZ0050AWZZ J AB Screw,ø1.4×2.5mm
503 LX-BZ0051AWZZ J AB Screw,ø1.4×3.8mm
504 LX-BZ0823AFZZ J AA Screw,ø1.4×1.2mm
505 LX-JZ0027AWZZ J AA Screw,ø1.7×3.5mm
506 LX-JZ0167AFZZ J AB Screw,ø1.4×3.0mm
507 LX-WZ9290AFZZ J AA Washer,ø0.8×ø2.4×0.25mm
508 LX-WZ9296AFZZ J AA Washer,ø1.5×ø3.5×0.25mm
M901 RMOTV0031AWZZ J AW Motor [Spindle]
M902 RMOTS0002AWZZ J AT Motor [Sled]
M903 RMOTV0033AWZZ J AW Motor [Lift]
CABINET PARTS
201 GCABA3005AWM1 J AX Top Cabinet Unit
202 GCABB3005AWM1 J AU Bottom Cabinet Unit
[MD-MT866H]
202 GCABB3006AWM1 J Bottom Cabinet Unit
[MD-MT866W]
203 GCABA1213AWSA J AM Center Cabinet
204 LHLDZ3017AWM1 J AQ Main Frame Unit
205 HDECQ0629AWSA J AM Decoration Plate
206 GMADI0003AWSA J AD Decoration Window
208 JKNBZ0747AWSA J AG Button,Operation
209 GCOVH1026AWSA J AE Cover,Shuttle Knob B
210 GCOVH1019AWSA J AE Cover,Shuttle Knob A
211 JKNBZ0748AWSA J AB Button,Record
214 LANGZ0035AWM1 J AH Bracket
215 LHLDZ1281AWZZ J AC Holder,LCD
216 RUNTZ0023AWZZ J AZ LCD
219 GCOVH1018AWZZ J AD Cover,PWB
220 LANGT0081AWFW J AC Case,Shuttle Knob
221 JKNBZ0750AWSA J AC Knob,Shuttle
222 MSPRD0148AWFJ J AB Spring,Shuttle Knob
223 LHLDZ1286AWSA J AC Holder,Shuttle Knob
224 JKNBK0081AWSA J AE Knob,Eject
226 GCOVH1020AWZZ J AB Cover,Extension Terminal A
227 GCOVH1021AWZZ J AB Cover,Extension Terminal B
228 QTANB9028AWFQ J AC Extension Terminal,A
229 LHLDZ1282AWZZ J AF Holder,Battery
230 LANGZ0031AWM2 J AG Battery Terminal,+
231 GFTAB1029AWSA J AE Cover,Battery
232 QTANB9032AWFQ J Battery Terminal,-
233 PSHEZ0085AWZZ J AC Sheet,Insulation
234 LANGT0080AWFW J AC Bracket,Lock
235 GCOVH1023AWSA J AB Cover,Charging Stand
237 PSHEZ0097AWZZ J AB Sheet,PWB
238 PSHEZ0098AWZZ J AB Sheet,Protection
241 PSPAZ0027AWZZ J AB Spacer,Main Frame
242 PSPAZ0028AWZZ J AA Spacer,PWB A
243 PSPAZ0030AWZZ J Spacer,PWB B
244 QTANB9029AWFQ J AC Extension Terminal,B
246 PCUSG0065AWZZ J Cushion,LCD Bracket
247 JKNBZ0746AWSA J AH Button,Mode/Edit
248 PSHEZ0084AWZZ J AC Sheet,Flexible PWB
249 TCAUS0049AWZZ J Label,Class 3B A
250 TCAUS0050AWZZ J Label,Class 3B B
251 PSHEZ0105AWZZ J AA Sheet,Frame
252 PSPAZ0031AWZZ J Spacer,Cabinet
253 PCUSG0068AWZZ J Cushion,Terminal
601 LX-BZ0047AWFC J AB Screw,ø1.4×1.5mm
602 LX-BZ0048AWFN J AC Screw,ø1.4×2.5mm
603 LX-BZ0058AWFN J Screw,ø1.4×2.5mm
604 LX-BZ1008AFFC J AB Screw,ø1.4×2mm
– 3 –
