Sharp MD-MT866H Service Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
MD-MT866H/MD-MT866W
ACCESSORIES/PACKING PARTS (MD-MT866H)
1 GCASZ0002AWSA J AL Battery Case
1 2 RADPA7045AWZZ J AX AC Adapter [Except for U.K.]
1 2 RADPA8046AWZZ J AY AC Adapter [For U.K.]
3 RPHOH0176AFSA J AT Headphonese
4 RRMCW0007AWSA J BH Remote Control
5 SPAKC1103AWZZ J Packing Case
6 QCNWG0422AFZZ J AQ Connecting Cord,Optical Type
7 SPAKA0284AWZZ J Packing Add.
9 TCADS0003AWZZ J AB Service Card
10 TCAUH0066AWZZ J Caution
13 TINSE0334AWZZ J AE Operation Manual [For U.K.]
13 TINSZ0611AWZZ J AN Operation Manual
[Except for U.K.]
14 TINSE0336AWZZ J AC Quick Guide
15 SPAKZ0699AWZZ J AC Adapter Pad
16 TLABZ0695AWZZ J AA Label,Caution
17 TCAUH0072AWZZ J Sheet,Caution
18 UBAGC0005AWZZ J AD Battery Carrying Case
19 UBAGC0006AWSA J AH Carrying Case
20 UBATM0006AWZZ J AZ Battery
21 SPAKZ0692AWZZ J Sheet,Bubble
22 RUNTZ0028AWM1 J BE Charging Stand
23 QCNWG0382AFZZ J AK Connecting Cord,RCA Type
24 SPAKZ0490AWZZ J AC Spacer
ACCESSORIES/PACKING PARTS (MD-MT866W)
GCASZ0002AWSA J AL Battery Case
QCNWG0382AFZZ J AK Connecting Cord,RCA Type
QCNWG0422AFZZ J AQ Connecting Cord,Optical Type
1 RADPA5051AWZZ J AC Adapter
1 RADPA5052AWZZ J AC Adapter
1 RADPA6049AWZZ J AC Adapter
RPHOH0176AFSA J AT Headphonese
RRMCW0007AWSA J BH Remote Control
RUNTZ0028AWM1 J BE Charging Stand
SPAKA0284AWZZ J Packing
SPAKC1104AWZZ J Packing Case
SPAKZ0678AWZZ J AC Adapter Pad
SPAKZ0692AWZZ J Sheet,Protection
TCAUA0040AWZZ J AB Sheet,Caution [For Taiwan]
TCAUH0066AWZZ J Caution
TGANZ0028AW64 J Guarantee Card [For Taiwan]
TINSE0335AWZZ J Operation Manual
[For Australia/New Zealand]
TINSZ0612AWZZ J Operation Manual
[Except for Australia/New
Zealand]
TLABH0055AWZZ J AF Sheet,E/C Comparison
TLABS0294AWZZ J Label,CPA
TLABZ0600AWSA J AC Label,Made in Malaysia
TLABZ0695AWZZ J AA Label,Caution
TLSTS0014AWZZ J AB SS List [For Taiwan]
TSPC-0785AWZZ J Label,Specifications B
[For Thailand]
TSPC-0786AWZZ J Label,Specifications [For Taiwan]
TSPC-0787AWZZ J Label,Specifications A
[For Thailand]
UBAGC0005AWZZ J AD Battery Carrying Case
UBAGC0006AWSA J AH Carrying Case,Unit
UBATM0006AWZZ J AZ Battery
92LGCARD1266E1 J AC Guarantee Card
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A 92LPWB3525MDSS J — Main
PWB-B 92LPWB3481KEYS J — LCD
OTHER SERVICE PARTS
UDSKM0001AFZZ J AZ Recording Mini Disc
88GMMD-110 J BV High Reflection Disc MMD-110
(TEAC Test MD)
88GMMD-213A J BT Low Reflection Disc MMD-213A
(TEAC Test MD)
CHARGING STAND PARTS
22 RUNTZ0028AWS1 J Charging Stand
22- 1 GCABA1223AWSA J AF Front Cabinet
22- 2 ———— — Back Cabinet Unit
(Not Replacement Item)
22- 3 LHLDZ1283AWSA J AE Remote Control Stand
22- 4 LHLDZ1285AWSA J AF Stand
22- 5 GLEGG0002AWZZ J AB Cushion A
22- 6 GLEGG0003AWZZ J AB Cushion B
22- 7 XEBSN20P05000 J Screw,ø2×5mm
– 4 –
