Sharp MX-2314N Start Guide

7
PART NAMES
Main power
switch
Tray 1
Tray 2 (when paper feed tray is installed)*
Tray 3 (when paper feed tray is installed)*
Tray 4 (when paper feed tray is installed)*
Bypass tray
Front cover
Output tray
(Centre tray)
Automatic document feeder
* Peripheral device.
USB connector (A type)
Exit tray unit (right tray)*
Keyboard*
[POWER] key (
)
IMAGE SEND mode indicators (
)
•LINE indicator
This lights up during transmission or
reception of a fax or Internet fax. This also
lights during transmission of an image in
scan mode.
•DATA indicator
This blinks when a received fax or Internet
fax cannot be printed because of a
problem such as out of paper.
This lights up when there is a transmission
job that has not been sent.
Operation panel
[JOB STATUS] key (
)
PRINT mode indicators (
)
•READY indicator
Print jobs can be received when this indicator is lit.
•DATA indicator
This blinks while print data is being received and lights steadily
while printing is taking place.
Touch panel
[HOME] key (
)
[SYSTEM SETTINGS] key (
)

Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
