Sharp MX-2614N

SHARP
TEST SIMULATION
47
56
MFP Data Import & Export
1
Transfer data execute (MFP/SD Card/SRAM
& EEPROM)
2
Export/Import EEPROM/SD Card & HDD
data
3
Document filing data backup to USB
4
Job log data backup to USB
5
Export Adjustment & Settings data to USB
6
Output Jam/Trouble data
7
Export Syslog data to USB
11
Copy the SD card data to option HDD
12
Copy option HDD to the SD card
60
Memory Operation & Test
1
SDRAM read/write test (MFP PWB)
61
LSU Writing Adjustment/Test
1
LSU test (Polygon & BD detection check)
3
LSU power auto setup
4
LSU position adjustment (CMYK)
62
HDD Operation & Test
1
HDD/SD Card format
2
HDD partial read/write check
3
HDD read/write check (all areas)
6
Smart (HDD) self diagnostic test
7
Smart (HDD) self diagnostic error log
8
HDD/SD Card format (excluding system &
operation manual area)
10
Job completion list deletion (with job log)
11
Document filing data deletion
12
Enable/disable auto format for HDD trouble
13
HDD format (manual area only)
14
Delete document filing management data
63
CCD Operation & Adjustment
1
Shading correction data display
2
Shading correction execution (force)
3
CCD gamma & colour correction adjust.
4
SIT chart patch density list display
5
CCD gamma & colour correction reset.
6
Print engine colour balance
7
Standard target colour calibration set-up
8
Standard scanner target reset (Service)
11
Colour Balance setting (Factory Mode).
64
Self Test Print
1
Test print (Colour mode)
64
Self Test Print
2
Test print (B/W mode)
4
Printer self print test
5
Printer self print test (PCL)
6
Printer self pint test (PS)
7
Adjustment pattern print (Sim46-21)
65
LCD Operation & Adjustment
1
LCD touch panel adjustment
2
LCD touch panel adjustment result display
5
Operation panel key input test
66
Fax Control Settings & Adjustments
1
Fax Soft SW setting:-
SW24
Communication Signal sending
level (bits 1-8):-
Default Value (Australia/NZ)
00001011
SW27-4
V.34 mode function (call
arrival):-
0 = V.34 valid.
1 = V.34 invalid.
SW27-5
V.34 mode function (polling
when calling):-
0 = V.34 valid.
1 = V.34 invalid.
SW27-6
V.34 mode function (manual
communication):-
0 = V.34 valid.
1 = V.34 invalid.
SW33-6,7
Transmission cable amplitude
equaliser:-
00 = 0dB
01 = 4dB
10 = 8dB
11 = 12dB
2
Country code default set (Fax)
3
Fax PWB controller memory check
4
Fax signal line check (Max level)
5
Fax signal line check (Soft SW setting level)
6
Fax list print (confidential registration)
7
Fax memory printout (all data)
8
Fax sound message setup
9
Fax signal line check (Soft SW setting)
10
Fax all memory clear
11
Voice signal check (line/speaker 300bps)
12
Voice signal check (line/speaker 300bps)
