1-58
BEFORE USING THE MACHINE
8
Grasp the developer cartridge lock and
replace it on the machine.
9
Hold the developer cartridge with one
hand and slowly remove the seal with
the other hand.
Slowly pull the seal straight and horizontally out.
If excessive force is used or the seal is pulled out diagonally, it may tear.
There is a mark (red belt) on the end of the seal. After removing the seal, be sure to verify that the mark (red belt) is on
the end of the seal.
If the seal has been cut on the developer cartridge, the cartridge cannot be used. Replace with a new developer
cartridge.
10
Close the main charger cover and rotate
the lock levers in the direction of the
arrows to lock the cover.
When the lock levers are vertical, the cover is locked.
11
Install the toner collection container.
☞
REPLACING THE TONER COLLECTION
CONTAINER (page 1-52)
(1)
(2)
To Next Page
