MX-M200D SIMULATIONS 7-24
26 43 Side void amount setting
Used to set the left and right side void amounts. The left side void amount and the right side void amount
can be set individually. Select an item to be changed with the arrow keys and change the set value to a
desired value. The setting range is 0-10. When the value is increased by 1, the void amount is increased by
0.5mm. The default is 5 (= 2.5mm).
Display: Set item
1:SIDE BOID(L) : Left side void amount setting
2:SIDE VOID(R) : Right side void amount setting
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Shifts to the sub code input window.
Default:
5 (Voide amount:
2.5mm)
51 Copy temporary stop function setting
Used to set whether copying is stopped temporarily when the paper exit tray full is detected. When the
electronic sort function is used, paper exit of 250 sheets (*1) or more can be used for one copy job. If, at that
time, copying (paper discharge) is continued with the tray full, a paper exit jam may occur. To avoid this,
copying is temporarily stopped by this setting.
(*1) 150 sheets when the job separator is installed.
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Shifts to the sub code input window.
Default:
1
54 LCD contrast PWM duty setting
Used to set the PWM duty (brightness) at the center value of LCD contrast.
* Setting range: 30-70
* When [OK] key or [START] key is pressed, the set value of LCD contrast is immediately reflected.
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Shifts to the sub code input window.
Default:
50
Main
code
Sub
code
Contents Remark
(Item selection)
Sim26-43 SIDE VOID Sim26-43 SIDE VOID Sim26-43 SIDE VOID
2
1:SIDE VOID(L)
2:SIDE VOID(R)
[ 0- 10]
3
3
3
1:SIDE VOID(L)
2:SIDE VOID(R)
[ 0- 10]
3
3
4
1:SIDE VOID(L)
2:SIDE VOID(R)
[ 0- 10]
4
3
4
(Value input) (Settlement)
[OK] key or [START] Key
Numeric Key
Key, Key
Sim26-51 COPY STOP
1:COPIES STOP
0=NON STOP
1=STOP
[ 0-1]
0
1
Display: Setting
0 : Temporary stop cancel
1 : Temporary stop
Sim26-54 LCD DUTY
1:LCD PWM DUTY
[ 30- 70]
50
50
