Sharp MX-M266N

MAINTENANCE
SHARP
10
MAINTENANCE SCHEDULE:
100K
150K
200K
300K
PROCESS SECTION:
X
Replace: Developer [MX-312GV]
X
Replace: Toner Filter [MX-312TF]
X
Check/Clean Toner Sensor Head.
X
Replace: OPC Drum [MX-312GR]
X
X
Replace: Maintenance Kit [MX-312KA]:-
 Drum Separation Pawls x 2
 Cleaning Blade.
 Main Charge Unit.
X
X
X
Replace: Process Frame Unit [MX-312DU]:-
(includes Cleaner Blade, Main Charge Unit & Drum
Separation Pawls)
Check/Clean LSU Dustproof Glass
X
Sim 24-05 Clear DV_K (Black) Counter.
X
Sim 24-04 Clear DRUM CTRG K (Black) Counter.
X
Clear MAIN CHARGER K (Black) Counter.
X
Clear DRUM BLADE K (Black) Counter.
X
Clear MAINTENANCE [ALL] Counter.
X
Clear OZONE FILTER Counter.
X
Sim 25-02* Toner Concentration Auto Adjustment - Select K.
Note* When Sim 25-02 is executed, the Developer Counter
(Sim 24-05) is also cleared automatically.
IMAGE QUALITY ADJUSTMENT (After Replacement Described Above):
X
Sim 46-02 Check/Adjust Copy Exposure Density (B/W).
RSPF:
Check/Clean PF Rollers - replace every 100K.
Check/Clean Torque Limiter - replace every 400K.
Clean all RSPF sensors.
GENERAL
Clean all optics, CCD, and white reference plate.
Replace Ozone Filter [PFiLZ0041QSZZ].
TRANSFER SECTION:
X
X
Replace: Transfer Roller Unit [MX-312TX].
X
X
Sim 24-04 Clear TC UNIT Counter.
PAPER FEED & TRANSPORT:
Check/Clean ALL Transport Paper Guides.
Check/Clean ALL Paper Path Sensors.
Check/Clean PF Roller (Cassette & Bypass Tray).
X
Replace: Cassette PF Roller Kit [MX-312RT] when each Tray
reaches 100K or 1 year of use.
X
Replace: Bypass Tray Roller Kit [MX-312MR] when the Bypass
Tray reaches 100K or 1 year of use.
