Sharp MX-M266N

SHARP
COIN VEND INTERFACE
13
All MX series machines have a coin vend interface located on the PCU Main PWB. The vending device
activates various signals to indicate paper sizes and operation.
Connector Manufacture: JST (www.jst.com)
Connector Type & Part Code (Wire Side) PND series / PNDP-16V-Z
Before connecting a third party auditor, the device should confirm to the following:-
a. The auditor interface should be optically isolated from the copier.
b. The device should be Power Supply Unit independent (plug top adaptor and not internal).
c. The plug top adapter should have a reinforced insulation barrier.
d. The audit device MUST comply & display the relevant safety approval mark (C-Tick & CE equivalent).
To enable coin vend function, test simulation 26 –03 should be set as required:-
COIN VENDOR MODE
Diagnostic
Setting
The specified quantity
is completed.
Remainder of money is left
Insufficient money during copy job
The specified
quantity is
completed.
No money remaining
Black/Colour
No money remaining
Colour
Remainder of money is
left
Condition 1
Condition 2
Condition 3
Condition 4
MODE 1
Operation 1
Operation 2
Operation 2
Operation 1
MODE 2
Operation 1
Operation 1
Operation 2
Operation 1
MODE 3
Operation 1
Operation 3
Operation 2
Operation 3
OPERATION 1: Wait for auto clear setting time (Default 60sec – can be changed by the system setting).
OPERATION 2: Auto clear is not made.
OPERATION 3: Setting is immediately cleared.
CONNECTOR SIGNALS
PIN
PCU PWB – CN9
1
+ 24v
Out
2
GND
Out
3
CV_B/W_COPY
In
4
CV_COUNT
Out
5
CV_START
Out
6
CV_CA
Out
7
CV_COLOUR_ COPY
In
8
CV_COLOUR1
Out
9
CV_STAPLE
Out
10
CV_COLOUR0
Out
11
CV_DUPLEX
Out
12
5v
Out
13
CV_SIZE0
Out
14
CV_SIZE1
Out
15
CV_SIZE2
Out
16
CV_SIZE3
Out
COLOUR SIGNALS
Colour Mode
(CL-COLOR1)
(CL-COLOR0)
B/W
0
0
Full Colour
1
1
Others
(Single/Two Colour)
0
1
PAPER SIZE SIGNALS
SIZE3
SIZE2
SIZE1
SIZE0
PAPER SIZE
0
0
0
0
NIL
0
0
0
1
A3
1
0
1
1
A3W
0
0
1
0
A4
0
0
1
1
LT
0
1
0
0
B4
0
1
0
1
LG
0
1
1
0
WLT
0
1
1
1
INV
1
0
0
0
B5
1
0
1
0
A5
1
0
0
1
EXTRA
