MX-M316N SIMULATION 6 – 16
21
21-1
Purpose
Setting
Function (Purpose)
Used to set the maintenance cycle.
Section
Operation/Procedure
* Do not change the default setting value of the maintenance
counter on SIM21-1. The replacement timing of the fusing clean-
ing roller, the filter and PS paper dust removal cleaner may not
clarify.
1) Select a target item of setting with scroll key on the touch
panel.
2) Enter the set value with 10-key.
3) Press [OK] key. (The set value is saved.)
22
22-1
Purpose
Adjustment/Setting/Operation data output/
Check
Function (Purpose)
Used to check the print count value in each
section and each operation mode.
(Used to check the maintenance timing.)
Section
Operation/Procedure
Change the display page with scroll key on the touch panel.
22-2
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
Used to check the total number of misfeed
and troubles. (When the number of total
jam is considerably great, it is judged as
necessary for repair.)
Section
Operation/Procedure
The paper jam, trouble counter value is displayed.
22-3
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
Used to check misfeed positions and the
misfeed count of each position.
* Presumption of the faulty point by this
data is possible.
Section
Operation/Procedure
The paper jam and misfeed history is displayed from the latest one
up to 50 items. (The old ones are deleted sequentially.)
22-4
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
Used to check the trouble (self diag) his-
tory.
Section
Operation/Procedure
The trouble history is displayed from the latest one up to 30 items.
(The old ones are deleted sequentially.)
Item/Display Content
Setting
range
Default
value
A MAINTENANCE
COUNTER
(TOTAL)
Maintenance
counter (Total)
0:
Default
1 - 300:
1K - 300K
999: Free
26CPM: 75K
31/35CPM:
100K
Item Display Content
Tot al
output
quantity
TOTAL OUT Total output
quantity of black
and white
All prints including
jams
Total use
quantity
TOTAL Total use quantity
of black and white
Effective paper
(including self print,
excluding jams)
Copy COPY Black and white
copy counter
Billing target
(excluding self print)
Print PRINT Black and white
print counter
Billing target
(excluding self print)
Document
filing
DOC FIL Black and white
document filing
print counter
Billing target
(excluding self print)
Other OTHER Black and white
other counter
Self print quantity
MACHINE JAM Machine JAM counter
RSPF JAM RSPF JAM counter
TROUBLE Trouble counter
1
: ‘15/Aug.
1
