Sharp MX-M550N

MX-M700N SIMULATION 7 – 45
* SPF1: DSPF front surface (CCD) / SPF2: DSPF back surface
(CCD)
46-39
Purpose
Adjustment
Function (Purpose)
Used to adjust sharpness of the FAX mode.
Section
—
Operation/Procedure
1) Enter the sharpness level with 10-key.
2) Press the [START] key.
The greater the adjustment value is, the greater the sharpness is.
46-45
Purpose
Adjustment
Function (Purpose)
Used to adjust the image density in the FAX
mode (600dpi).
Section
—
Operation/Procedure
1) Select the number corresponding to one of the following
adjustment items with 10-key. (Select one of 0 - 14.)
* Normal mode (Image density adjustment level)
* Normal mode (Image density adjustment level) (Half-tone
mode)
* Auto mode
* Auto mode (Half-tone mode)
2) Press the [START] key.
3) Enter the image density adjustment value with 10-key.
4) Press the [START] key.
The adjustment value is set.
To select paper (paper feed tray), perform the following procedures.
1) Enter 0 with 10-key.
2) Press [START] key. (The mode is changed to the paper feed
tray selection mode.)
3) Enter the number corresponding to the paper feed tray to be
used with 10-key.
4) Press [START] key. (The paper feed tray is selected.)
Item
Setting
range
Default
1 OC_AE AE mode (OC) 1 - 5
2
2 OC_CHARA Text mode (OC)
3
3 OC_MIX Text/Photo mode (OC)
4 OC_PHOTO Photo mode (OC)
5 SPF1_AE AE mode (SPF1)
2
6 SPF1_CHARA Text mode (SPF1)
3
7 SPF1_MIX Text/Photo mode
(SPF1)
8 SPF1_PHOTO Photo mode (SPF1)
9 SPF2_AE AE mode (SPF2)
2
10 SPF2_CHARA Text mode (SPF2)
3
11 SPF2_MIX Text/Photo mode
(SPF2)
12 SPF2_PHOTO Photo mode (SPF2)
13 CIS_AE AE mode (OC)
4
14 CIS_CHARA Text mode (OC)
3
15 CIS_MIX Text/Photo mode (OC)
16 CIS_PHOTO Photo mode (OC)
Item
Setting
range
1 Level 1 (Half-tone/ Sharpness:Light) 1 - 3
2 Level 2 (Sharpness:Medium light)
3 Level 3 (Normal/ Sharpness:Medium)
1
SIMULATION 46-31
SHARPNESS LEVEL SETUP. SELECT 1-16, AND PRESS START.
1.OC_AE 3 2.OC_CHARA 3 3.OC_MIX 3
4.OC_PHOTO 3 5.SPF1_AE 3 6.SPF1_CHARA 3
7.SPF1_MIX 3 8.SPF1_PHOTO 3 9.SPF2_AE 3
10.SPF2_CHARA 3 11.SPF2_MIX 3 12.SPF2_PHOTO 3
13.CIS_AE 3 14.CIS_CHARA 3 15.CIS_MIX 3
16.CIS_PHOTO 3
1
SIMULATION 46-39
FAX SHARPNESS LEVEL SETUP. SELECT 1-36, AND PRESS
START.
1:OC_NORMAL 3 2:OC_FINE 3 3:OC_FINE(H) 1
4:OC_SFINE 3 5:OC_SFINE(H) 1 6:OC_UFINE 3
7:OC_UFINE(H) 1 8:OC_600 3 9:OC_600(H) 1
10:SPF1_NORMAL 3 11:SPF1_FINE 3 12:SPF1_FINE(H) 1
13:SPF1_SFINE 3 14:SPF1_SFINE(H) 1 15:SPF1_UFINE 3
16:SPF1_UFINE(H) 1 17:SPF1_600 3 18:SPF1_600(H) 1
19:SPF2_NORMAL 3 20:SPF2_FINE 3 21:SPF2_FINE(H) 1
22:SPF2_SFINE 3 23:SPF2_SFINE(H) 1 24:SPF2_UFINE 3
25:SPF2_UFINE(H) 1 26:SPF2_600 3 27:SPF2_600(H) 1
28:CIS_NORMAL 3 29:CIS_FINE 3 30:CIS_FINE(H) 1
31:CIS_SFINE 3 32:CIS_SFINE(H) 1 33:CIS_UFINE 3
34:CIS_UFINE(H) 1 35:CIS_600 3 36:CIS_600(H) 1
Item
Setting
range
Default
0 TRAY SELECT Paper feed tray
selection
1 PRINT START Print start (Default)
2 EXP LEVEL Exposure level
selection
3 AUTO Auto 0 - 99 50
4 1.0 Exposure level 1
5 2.0 Exposure level 2
6 3.0 Exposure level 3
7 4.0 Exposure level 4
8 5.0 Exposure level 5
9 AUTO (H) Auto (Half-tone)
10 1.0 (H) Exposure level 1
(Half-tone)
11 2.0 (H) Exposure level 2
(Half-tone)
12 3.0 (H) Exposure level 3
(Half-tone)
13 4.0 (H) Exposure level 4
(Half-tone)
14 5.0 (H) Exposure level 5
(Half-tone)
1TRAY1 TRAY1
2TRAY2 TRAY2
3TRAY3 TRAY3
4TRAY4 TRAY4
5 BPT Manual paper feed
6 LCC Side LCC
SIMULATION 46-45
EXP.LEVEL SETUP SCANNER(600dpi). SELECT 0-5,AND PRESS
START.
0.AUTO 50 1.1.0 50 2.2.0 50
3.3.0 50 4.4.0 50 5.5.0 50
6.AUTO(H) 50 7.1.0(H) 50 8.2.0(H) 50
9.3.0(H) 50 10.4.0(H) 50 11.5.0(H) 50
: '07 Feb 15
