* For index paper, equivalent to 140-lbs.
* For index paper, equivalent to 140-lbs.
Specifications are subject to change for improvement without notice.
Supplies
The finisher and saddle stitch finisher require the following staple cartridge:
Staple cartridge for finisher and
saddle stitch finisher (approx. 5,000
per cartridge X 3 cartridges)
SF-SC11
Staple cartridge for saddle stitch
finisher (approx. 2000 per cartridge X
3 cartridges)
AR-SC3
STAPLE CARTRIDGE REPLACEMENT AND STAPLE
JAM REMOVAL
When a finisher is installed, a message will appear when the staple cartridge runs out of staples or a staple jam occurs.
Follow the procedure below to replace the staple cartridge or remove jammed staples.
Dimensions When tray is folded up: 700 mm (W) x 630 mm (D) x 1150 mm(H)
(27-9/16" (W) x 24-13/16" (D) x 45-9/32" (H))
When tray is extended: 813 mm (W) x 630 mm (D) x 1150 mm(H)
(32" (W) x 24-13/16" (D) x 45-9/32" (H))
Not including stopper (40 mm (1-37/64")) when attached to machine
Weight Approx. 54 kg (Approx. 119 lbs.) Approx. 75 kg (Approx. 165
lbs.
)
Overall dimensions when
attached to machine
1904 mm (W) x 630 mm (D) (Separation from machine 400 mm)
(75-15/16" (W) x 24-13/16" (D) (Separation from machine 15-3/4"))
Name Punch module (AR-PN4B)
Hole punching 3 holes
Allowed paper sizes for
punching
A3, B4, A4, A4R, B5, B5R, 11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R
Page weight 56 to 256 g/m
2
(15 to 68* lbs.)
Power supply Supplied from finisher / saddle stitch finisher
Dimensions 95 mm (W) x 560 mm (D) x 170 mm (H) (3-3/4" (W) x 22-1/16" (D) x 6-45/64" (H))
Weight Approx. 3.5 kg (Approx. 7.8 lbs.)
• The following papers cannot be stapled and punched:
Special papers such as transparency film and label sheets
• If mixed paper sizes are selected for stapling jobs, stapling will be automatically cancelled.
