Sharp MZ-80B - Chapter 3 Option Device Installation

Chapter 3
Option Device Installation
This chapter describes procedures for installing optional devices in the main cabinet of the MZ-
808 .
MZ-80RM
MZ-80GM
MZ-80EU
Expansion Memory Module:
32K byte RAM card
Graphic Memory 1:
8K byte RAM card
Expansion
1/0 Port
These optional devices must be installed properly according to procedures explained in this
chapter.
Other optional devices
are connected via the expansion I /0 port . General procedures and notes on
connecting optional devices
via the expansion I /0 port are contained in the last part of this chapter.
31
