Specifi cations
Model PG-D2500X
Display devices 0.55" DLP
®
Chip ×1
Resolution XGA (1024 × 768)
Lens F number F 2.4 – 2.6
Zoom Manual, ×1.20 (f = 19.0 – 22.7 mm)
Focus Manual
Input terminals Computer/Component
(mini D-sub 15 pin)
×1
S-Video (mini DIN 4 pin) ×1
Video (RCA) ×1
Audio (ø3.5 mm stereo minijack) ×1
Audio (RCA) ×1 (L/R)
Output terminal Computer/Component
(mini D-sub 15 pin)
×1
Control and
communication
terminals
USB (Type B) ×1
RS-232C (mini DIN 9 pin) ×1
Speaker 7W (Mono)
Projection lamp 210 W
Rated voltage AC 100 – 240 V
Rated frequency 50/60 Hz
Input current 2.8 A
Power consumption Eco+Quiet
Off
AC 100 V 274 W
AC 240 V 265 W
Eco+Quiet
On
AC 100 V 215 W
AC 240 V 210 W
Power consumption
(STANDBY Mode)
Quick Start AC 100 V 3.0 W
AC 240 V 3.7 W
Eco AC 100 V 0.32 W
AC 240 V 0.77 W
Operation temperature 41ºF to 95ºF (+5ºC to +35ºC)
Cabinet Plastic
Dimensions (main body only) [W × H × D] 11
52
/
64
" × 3
1
/
8
" × 9
19
/
64
"
(300 × 79 × 236 mm)
Weight (approx.) 6.2 lbs. (2.8 kg)
As a part of policy of continuous improvement, SHARP reserves the right to make design and
specifi cation changes for product improvement without prior notice. The performance specifi cation
fi gures indicated are nominal values of production units. There may be some deviations from these
values in individual units.
This SHARP projector uses a DLP
®
chip. This very sophisticated panel contains 786,432
pixels (micromirrors). As with any high technology electronic equipment such as large screen
TVs, video systems and video cameras, there are certain acceptable tolerances that the
equipment must conform to.
This unit has some inactive pixels within acceptable tolerances which may result in inactive dots
on the picture screen. This will not affect the picture quality or the life expectancy of the unit.
