Sharp PN-L802B Operation Manual

10
E
n
Floating menu
The menu can be moved to any position.
To move the menu, drag the background.
Title bar
is linked to pin / unpin.
Touch
to minimize the menu and show only the title bar. (Not pinned)
When the menu is minimized, touch
to return the menu to its original state. (Pinned)
When set to unpin on the tool bar, the menu is minimized.
Touch
to return the menu to its original state pinned.
Touch
to change the menu to horizontal display. The menu changes between vertical
and horizontal display each time this is touched.
TIPS
• The menu icon types that appear by default are the same as in the square menu and classic menu.
• In oating menu, 1 menu is used for the settings, even when using multiple pens. When using multiple pens, the line color
and width are the same for all pens.
• To move the oating menu to the pen tip of the touch pen, hold the pen down on the screen.
Setting to oating menu
1. Touch the “Settings” button (
) on the toolbar.
2. Select “Floating Menu” in “Menu”.
To return to the normal menu, select “Square Menu”.

Sharp PN-L802B Specifications

General

Pixel pitch	0.923 x 0.923 mm
Aspect ratio	16:9
Screen shape	Flat
LED backlight	Yes
Response time	6 ms
Display diagonal	80 \
Display brightness	300 cd/m²
Display technology	LCD
Touchscreen technology	Optical imaging
Contrast ratio (typical)	3000:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	203.2 cm
Product color	Gray
Display viewable area (HxV)	1771.2 x 996.3 mm
Audio input	1
RS-232 ports	2
AC input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	260 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
NVIDIA G-SYNC	No

Weight and Dimensions

Depth (without stand)	135 mm
Width (without stand)	1880 mm
Height (without stand)	1157 mm
Weight (without stand)	102000 g
