10
E
Part Names
1. Signal transmitter
2. POWER button (See page 19.)
3. MUTE button (See page 21.)
4. VOL +/- buttons (See page 21.)
BRIGHT +/- buttons (See page 21.)
Cursor control (
/ / / ) buttons
5. DISPLAY button (See page 22.)
6. MODE button (See page 22.)
7. INPUT button (See page 21.)
8. MENU button (See page 21.)
9. ENTER button (See page 21.)
10. RETURN button (See page 21.)
11. SIZE button (See page 21.)
n
Remote control unit
(Supplied with the PN-ZR01A (optional))
2
3
4
5
6
11
8
7
9
10
1. Brightness sensor
(Cannot be used with the monitor.)
2. Remote control sensor
3. Connection cable
4. Mounting bracket
n
Remote control sensor box
(Supplied with the PN-ZR01A (optional))
2
3
4
