Function Command Direction Parameter Reply Control/Response contents *
AUDIO SELECT HDMI[PC]
ASHP WR 0-1 0-1
0: HDMI, 1: AUDIO
○
HDMI[AV]
ASHA WR 0-1 0-1
0: HDMI, 1: AUDIO
DisplayPort
ASDI WR 1,3 1,3
1: AUDIO, 3: DisplayPort
AUDIO OUTPUT
AOUT WR 0-1 0-1
0: VARIABLE, 1: FIXED
○
COMMUNICATION
SETTING
RS-232C/LAN
SELECT
CTLS WR 0-1 0-1 0: RS-232C 1: LAN
○
BAUD RATE
BAUD WR 0-2 0-2 0: 9600bps, 1: 19200bps, 2: 38400bps
ID SETTING ID NO.SETTING IDST W 0-255 Sets the monitor’s ID number. (“0” means “no ID number”.)
○
R 0-255 Returns the monitor’s ID number.
ID NO. SETTING
(ONCE)
IDSL W 1-255 Sets a monitor ID number.
This ID number is only effective for the command immediately after this
command.
0 Clears the ID number if one has been designated.
ID NO. SETTING
(SUBSEQUENT)
IDLK W 1-255 Sets a monitor ID number.
This ID number is effective for the next and all subsequent commands after this
command.
0 Clears the ID number if one has been designated.
ID CHECK IDCK W 0 ID : xxx
IDLK : yyy
Displays monitor’s own ID number and the selected ID number on the screen.
ID DISPLAY IDDP W 0-2 0: OFF, 1: ON, 2: ON (turns OFF after 4 sec.)
(The IP address and MAC address are both displayed.)
-
COPY SETTING
VALUE
SETTING COPY
MODE
CPMD WR 0 0 Copy to all monitors.
○
1-255 1-255 Copy to the monitor with the set ID Number.
SETTING COPY
TARGET
CPTG WR 0 0 Copies the PICTURE menu settings.
1 1 Copies all the settings.
MONITOR menu
Function Command Direction Parameter Reply Control/Response contents *
MONITOR STDR WR 0-1 0-1 0: LANDSCAPE, 1: PORTRAIT
○
OSD H-POSITION OSDH WR 0-100 0-100
OSD V-POSITION OSDV WR 0-100 0-100
STANDBY MODE STBM WR 0-1 0-1 0: STANDARD, 1: LOW POWER
(“ERR" when SCHEDULE is effective.)
OFF IF NO OPERATION ATOF WR 0-1 0-1 0: OFF, 1: ON
POWER ON
DELAY
POWER ON
DELAY
PODS WR 0-1 0-1 0: OFF, 1: ON
INTERVAL PWOD WR 0-60 0-60 0: OFF, 1-60 seconds
SELF ADJUST SELF ADJUST AADJ WR 0-1 0-1 0: OFF, 1: ON
START TIMING AADD WR 10-200 10-200 10: 1 second through 200: 20 seconds
Controlling the Monitor with a PC (RS-232C)
