Sharp R-24ST Service Manual

R-24ST/R-2B34 - 7
SPECIFICATION
ITEM DESCRIPTION
Power Requirements 230 Volts
50 Hertz
Single phase, 3 wire earthed
Power Consumption 1.2 kW
Power Output 800W watts nominal of RF microwave energy
(measured by way of IEC 60705)
Operating frequency of 2450 MHz
Case Dimensions Width 449mm
Height 282mm including foot
Depth 366mm(R-24ST)
Dept 346mm(R-2B34)
Cooking Cavity Dimensions Width 287mm
Height 220mm
Depth 311mm
Turntable diameter 272mm
Control Complement Jog/Touch Control System
Clock (1.00-12.59 or 0.00-23.59) - 12HR or 24HR setting
Microwave Power for Variable Cooking
Repetition Rate;
HIGH .................. Full power throughout the cooking time
MEDIUM HIGH ...................... approx. 70% of Full Power
MEDIUM ................................ approx. 50% of Full Power
MEDIUM LOW ....................... approx. 30% of Full Power
LOW ...................................... approx. 10% of Full Power
EXPRESS DEFROST buttons
EXPRESS COOK buttons
POWER LEVEL button
STOP button
+1MIN/START button
TIMER/WEIGHT/PORTION knob
Net Weight Approx. 13.5 kg
WARNING
THIS APPLIANCE MUST BE EARTHED
IMPORTANT
THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:
GREEN-AND-YELLOW : EARTH
BLUE : NEUTRAL
BROWN : LIVE
PRODUCT SPECIFICATIONS
GENERAL INFORMATION
As part of our policy of continuous improvement, we reserve the right to
alter design and specifications without notice
