Sharp R-24ST Service Manual

R-24ST/R-2B34 - 35
PARTS LIST
ELECTRICAL PARTS
*
*
*
∆
*
∆
∆
Note: The parts marked ' ★ ' have voltages in excess of 250V.
The parts marked ' ∆ ' may cause undue microwave exposure when damaged, loosened or removed.
'
§' mark : Spare part delivery section.
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
CONTROL PANEL PARTS
3- 1 DPWBFC143WRKZ U Control unit 1 BC
3- 1A QCNCMA430DRE0 U 3-pin connector (CN-A) 1 AC
3- 1B QCNCMA414DRE0 U 2-pin connector (CN-B) 1 AB
3- 1C QCNCMA330DRE0 U 6-pin connector (CN-C) 1 AB
3- 1D RLCDSA036DRE0 U Liquid crystal display 1 AP
3- 1E LHLD-A179WRF0 U LED holder 1 AE
3- 1F PSHEPA601WRE0 U LED sheet 1 AD
C1 VCEAB31CW227M U Capacitor 220 uF 16V 1 AA
C10 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C20 VCEAB31VW227M U Capacitor 220 uF 35V 1 AA
C21 VCEAB31VW106M U Capacitor 10 uF 35V 1 AB
C22 VCEAB31HW104M U Capacitor 0.1 uF 50V 1 AM
C40 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C41 VCEAB31CW476M U Capacitor 47 uF 16V 1 AA
C42 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C43-44 VCKYD11CY103N U Capacitor 0.01 uF 16V 2 AA
C50 VCCCF61HH330J U Capacitor 33 pF 50V 1 AA
C60-61 VCKYD11CY103N U Capacitor 0.01 uF 16V 2 AA
C70 VCEAB31VW476M U Capacitor 47 uF 35V 1 AA
C71 VCEAB31VW107M U Capacitor 100 uF 35V 1 AB
C80 VCKYD11CY103N U Capacitor 0.01 uF 16V 1 AA
D1-3 VHD1N4005E61B U Diode (1N4005E) 3 AA
D10 VHD1SS270A/-1 U Diode (1SS270ATA) 1 AA
D20 VHD1SS270A/-1 U Diode (1SS270ATA) 1 AA
D70-71 VHD1N4005E61B U Diode (1N4005E) 2 AA
D72-74 VHD1SS270A/-1 U Diode (1SS270ATA) 3 AA
D80 VHD1SS270A/-1 U Diode (1SS270ATA) 1 AA
IC1 RH-IXA086DRZZ U LSI 1 AZ
JW1 FW-VZA259DRZZ U 1-pin harness 1 AE
LED1-3 VHPSLP7117E-3 U Light emitting diode 3 AC
Q20 VSKRA101M//-3 U Transistor (KRA101M) 1 AA
Q21 VSKRC105M//-3 U Transistor (KRC105M) 1 AB
Q30 VSKRC101M//-3 U Transistor (KRC101M) 1 AB
Q40 VS2SA1267Y/-3 U Transistor (2SA1267Y) 1 AB
Q70 VSKRC105M//-3 U Transistor (KRC105M) 1 AB
R1-5 VRS-L63DA102J U Resistor 1.0k ohm 2W 5 AB
R10-11 VRD-B12EF273J U Resistor 27k ohm 1/4W 2 AA
R12 VRD-B12EF103J U Resistor 10k ohm 1/4W 1 AA
R20 VRD-B12EF822J U Resistor 8.2k ohm 1/4W 1 AA
R30 VRD-B12EF332J U Resistor 3.3k ohm 1/4W 1 AA
R31 VRD-B12EF153J U Resistor 15k ohm 1/4W 1 AA
R40 VRD-B12HF152J U Resistor 1.5k ohm 1/2W 1 AA
R41 VRD-B12EF102J U Resistor 1.0k ohm 1/4W 1 AA
R42 VRD-B12EF153J U Resistor 15k ohm 1/4W 1 AA
R50 VRN-B12EK103F U Resistor 10k ohm 1/4W 1 AA
1- 1 RH-DZA048WRE0 U High voltage rectifier 1 AM
1- 2 FPWBFA308WRE2 U Noise filter 1 AQ
1- 3 QACCVA006URE2 U Power supply cord 1 AL
C RC-QZA295WRZZ U High voltage capacitor 1 AP
F QFS-CA025WRE0 U Fuse F8A 1 AC
FM RMOTEA003URE0 U Fan motor 1 AQ
MG RV-MZA243WRE1 U Magnetron 1 BA
OL RLMPTA066WRE0 U Oven lamp 1 AK
SW1 QSW-MA147WRZZ J Monitored latch switch 1 AC
SW2 QSW-MA146WRZZ J Monitor switch 1 AC
SW3 QSW-MA147WRZZ J Stop switch 1 AC
T RTRN-A018URE0 U High voltage transformer 1 BE
TC RTHM-A122WRZZ U Thermal cut-out 125˚C (OVEN) 1 AG
TTM RMOTDA226WRE0 U Turntable motor 1 AQ
CABINET PARTS
2- 1 GCABUA573WRT0 U Outer case cabinet (W) 1 AT
2- 1 GCABUA027URP0 U Outer case cabin (IN) 1 AT
2- 2 GLEGPA057WRE0 U Foot 2 AB
