Sharp R-24ST Service Manual

R-24ST/R-2B34 - 36
Note: The parts marked ' ★ ' have voltages in excess of 250V.
The parts marked ' ∆ ' may cause undue microwave exposure when damaged, loosened or removed.
'
§' mark : Spare part delivery section.
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
PARTS LIST
CONTROL PANEL PARTS Contin......
OVEN PARTS
4- 1 DOVN-A013URT1 U Oven cavity 1 BA
4- 2 LBNDKA111WRP0 U H.V. Capacitor holder 1 AD
4- 3 PHOK-A001URF1 U Latch hook 1 AH
4- 4 NFANJA029WRE0 U Fan blade 1 AM
4- 5 PDUC-A638WRF2 U Fan duct 1 AE
4- 6 LANGFA169WRP6 U Chassis support 1 AE
4- 7 PPACGA002URE0 U Seal packing 1 AB
4- 8 PCUSUA017URE0 U HVC deflection cushion 1 AC
4- 9 PCOVPA309WRE0 U Waveguide cover 1 AC
4-10 PDUC-A581WRF3 U Air intake duct 1 AE
4-11 GDAI-A280WRP1 U Base plate 1 AQ
4-12 PSPAGA001WRE0 U Vibration proof cushion 1 AA
R60-61 VRD-B12EF103J U Resistor 10k ohm 1/4W 2 AA
R62-63 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 2 AA
R64 VRD-B12EF104J U Resistor 100k ohm 1/4W 1 AA
R70-71 VRS-B13AA361J U Resistor 360 ohm 1W 2 AA
R72 VRD-B12EF822J U Resistor 8.2k ohm 1/4W 1 AA
R73 VRD-B12EF153J U Resistor 15k ohm 1/4W 1 AA
R80 VRD-B12EF153J U Resistor 15k ohm 1/4W 1 AA
R81 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 1 AA
RW VRD-B12EF104J U Resistor 100k ohm 1/4W 1 AA
RY1 RRLY-A080DRE0 U Relay (OJ-SH-124LM) 1 AG
RY2 RRLY-A094DRE0 U Relay (OMIF-S-112LM) 1 AL
SP30 RALM-A014DRE0 U Buzzer (PKM22EPT-THAI) 1 AG
SW60 RVR-BA018WRE0 U Encoder 1 AH
VRS1 RH-VZA032DRE0 U Varistor (10G471K) 1 AC
ZD1 VHEHZ12C1//-1 U Zener diode (HZ12C1) 1 AA
ZD20-21 VHEHZ12C1//-1 U Zener diode (HZ12C1) 2 AA
ZD40 VHEHZ4C3///-1 U Zener diode (HZ4C-3) 1 AA
ZD70-71 VHEHZ7C2///-1 U Zener diode (HZ7C2) 2 AA
3- 2 FPWBFA053URK0 U Switch unit assembly 1 BC
3- 3 HPNLCR022URF0 U Control panel frame (R-24ST R-2B34(ST/AL/K) 1 AL
3- 3 HPNLCW072URF0 U Control panel frame (R-2B34(W) 1 AL
3- 4 GMADIA032URR0 U Display window printed (All) 1 AH
3- 5 JBTN-S009URT0 U Select button painted (R-24ST R-2B34(ST/AL/K) 1 AE
3- 5 JBTN-W029URF0 U Select button painted (R-2B34(W) 1 AF
3- 6 JKNBKS001URT0 U Rotary knob (R-24ST R-2B34(ST/AL/K) 1 AH
3- 6 JKNBKW011URF0 U Rotary knob (R-2B34(W) 1 AD
3- 7 HDECQA007URR0 U C/P Decoration printed (R-24ST R-2B34(ST) 1 AE
3- 7 HDECQW003URR0 U C/P Decoration printed (R-2B34(W) 1 AE
3- 7 HDECQA013URR0 U C/P Decoration printed (R-2B34(AL) 1 AE
3- 7 HDECQK004URR0 U C/P Decoration printed (R-2B34(K) 1 AE
3- 8 XEPSD30P10XS0 U Screw; 3mm x 10mm 9 AA
3- 9 DPNLCS045URK0 U C/P Assy (R-24ST R-2B34(ST) 1 AZ
3- 9 DPNLCW080URK0 U C/P Assy (R-2B34(W) 1 BA
3- 9 DPNLCA135URK0 U C/P Assy (R-2B34(AL) 1 BA
3- 9 DPNLCK011URK0 U C/P Assy (R-2B34(K) 1 BA
3- 10 LSTPPA015URF0 U Stopper 1 AC
