R-24ST/R-2B34 - 37
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
2. REF. NO.
3. PART NO. 4. DESCRIPTION
PARTS LIST
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
SCREWS,NUTS AND WASHERS
7- 1 LX-CZA001URE0 U Screw: 4mm x 12mm 18 AA
7- 2 XHTSD40P08RV0 U Screw: 4mm x 8mm 4 AA
7- 3 LX-LZA011WRE0 U Rivet 1 AA
7- 4 LX-NZA026WRE0 U M4 Nyloc nut 1 AA
7- 5 XHPSD40P06000 U Screw: 4mm x 6mm 2 AA
7- 6 LX-HZA001URE0 U Special screw 1 AA
7- 7 XOTSE40P10000 U Screw: 4mm x 12mm R-24ST /R-2B34(W) 2 AA
7- 7 XOTSF40P10000 U Screw: 4mm x 12mm R-2B34(K/AL/ST) 1 AA
7- 9 XHPSD40P08K00 U Screw: 4mm x 8mm 1 AA
7- 10 XJPSD40P10X00 U Screw: 4mm x 10mm 1 AA
7- 11 LX-CZA030WRE0 U Special screw 1 AA
MISCELLANEOUS
6- 1 FROLPA070WRK3 U Roller stay 1 AM
6- 2 NTNT-A060WRE0 U Turntable 1 AN
6- 3 TINS-A245URR0 U Operation manual/ Cookbook 1 AV
6- 4 TLABMA166URR0 U Menu label 1 AE
6- 5 QW-QZA001URE0 U High voltage wire B 1 AE
6- 6 FW-VZA059URE3 U Main harness 1 AN
6- 8 PCLI-A001URE0 U Harness clip 1 AA
5 CDORFS016URK0 U Door assembly R-24ST / R-2B34(ST) 1 BG
5 CDORFA087URK0 U Door assembly R-2B34(AL) 1 BH
5 CDORFK007URK0 U Door assembly R-2B34(K) 1 BH
5 CDORFW022URK0 U Door assembly R-2B34(W) 1 BH
5-1 FDORFA299WRT1 U Door panel assembly[All models] 1 AU
5-2 FWAKPW029URK0 U Door frame assy R-2B34(W) 1 BD
5-2 FWAKPK003URK0 U Door frame assy R-2B34(K) 1 BD
5-2 FWAKPA038URK0 U Door frame assy R-2B34(AL) 1 BD
5-2 FWAKPS017URK0 U Door frame assy R-24ST /R-2B34(ST) 1 BE
5-3 GWAKPR013URF0 U Door frame (moulded) 1 AM
5-4 PGLSPA013URE0 U Outer door glass[All models] 1 AM
5-5 LSTPPA013URF0 U Latch head[All models] 1 AD
5-6 MSPRTA141WRE0 U Latch spring[All models] 1 AA
5-7 PSHEPA482WRE0 U Inner Sealer film[All models] 1 AH
5-8 LSTPPA020URF0 U Glass stopper [All models] 1 AB
5-9 XEBSD30P06000 U Door Frame screw 4 AA
5-10 JHNDPS002URT0 U Handle (painted) R-24ST / R-2B34(K/AL/ST) 1 AW
5-10 JHNDPW001URF0 U Handle (moulded) R-2B34(W) 1 AU
5-11 XEPSD30P10XS0 U Handle/glass stopper screw 2 AA
5-12 HDECQW005URP0 U Door decoration R-2B34(W)) 1 AR
5-12 HDECQS002URP0 U Door decoration R-2B34(ST)R-24ST 1 AR
5-12 HDECQA014URP0 U Door decoration R-2B34(AL) 1 AR
5-12 HDECQK007URP0 U Door decoration R-2B34(K) 1 AR
5-13 GCOVHA366WRF0 U Choke cover [All models] 1 AG
DOOR PARTS
NOTE: WHEN REPLACING THE POWER GRD. M4 NYLOC NUT MUST BE REFITTED.
∆
*
Note: The parts marked ' ★ ' have voltages in excess of 250V.
The parts marked ' ∆ ' may cause undue microwave exposure when damaged, loosened or removed.
'
§' mark : Spare part delivery section.
To Next Page
