R-350J
30
∆
∆
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 3. PART NO.
2. REF. NO. 4. DESCRIPTION
Note: The parts marked "
∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
5- 4 HPNL-A811WRRZ Door screen 1 AU
5- 5 LSTPPA188WRF0 Latch head 1 AG
5- 6 MSPRTA187WRE0 Spring 1 AC
5- 7 GCOVHA450WRFZ Choke cover 1 AG
MISCELLANEOUS
6- 1 FROLPA090WRK0 Turntable support 1 AQ
6- 2 NTNT-A117WREZ Turntable 1 AS
6- 3 FW-VZB996WREZ Main wire harness 1 AT
6- 4 TCAUHA214WRR0 K caution label 1 AC
6- 5 TLABMB006WRRZ Menu label 1 AF
6- 6 TINSEB061WRRZ Instruction book 1 AM
6- 7 FW-VZB888WREZ Switch harness 1 AU
SCREWS,NUTS AND WASHERS
7- 1 XHPSD40P08K00 Screw : 4mm x 8mm 5 AA
7- 2 XOTSD40P12RV0 Screw : 4mm x 12mm 5 AA
7- 3 LX-CZA073WRE0 Special screw 2 AC
7- 4 LX-CZ0052WRE0 Special screw 2 AA
7- 5 LX-EZA042WRE0 Special screw 2 AB
7- 6 XHPSD30P06000 Screw : 3mm x 6mm 1 AA
7 -7 XHPSD40P08000 Screw : 4mm x 8mm 5 AA
7- 8 XHTSD40P08RV0 Screw : 4mm x 8mm 4 AA
7- 9 XHTSD40P08000 Screw : 4mm x 8mm 1 AA
7-10 XOTSD40P08000 Screw : 4mm x 8mm 12 AA
7-11 XOTSE40P08000 Screw : 4mm x 8mm 1 AA
7-12 XOTSD40P12000 Screw : 4mm x 12mm 1 AA
