Sharp R-350J User Manual

R-350J
29
∆
∆
∆
∆
*
*
*
*
∆
*
*
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 QSW-MA147WRZZ 1st. latch/2nd. interlock relay control relay conrol switch 2AG
1- 1 QSW-MA137WRE0 " / " (Interchangeable) 2 AH
1- 1 QSW-MA085WRE0 " / " (Interchangeable) 2 AF
1- 2 QSW-MA148WRZZ Monitor switch 1 AF
1- 2 QSW-MA138WRE0 Monitor switch (Intercangeable) 1 AH
1- 2 QSW-MA086WRE0 Monitor switch (Intercangeable) 1 AF
1- 3 QACC-A142WRZZ Power supply cord 1 AQ
1- 3 QACC-A139WRZZ Power supply cord (Interchangeable) for production use 1--
1- 3 QACC-A156WRZZ Power supply cord (Interchangeable) for production use 1--
1- 4 FH-DZA111WRKZ High voltage rectifier assembly 1 AU
1- 5 RC-QZA293WRZZ High voltage capacitor 1 AV
1- 5 RC-QZA273WRZZ High voltage capacitor (Interchangeable) for production use 1--
1- 6 RMOTEA405WRZZ Fan motor 1 AX
1- 6 RMOTEA390WRE0 Fan motor (Interchangeable) 1 AW
1- 7 QFS-TA014WRE0 Temperature fuse 150deg.C (magnetron) (oven) 2 AG
1- 8 RLMPTA083WRZZ Oven lamp 1 AM
1- 8 RLMPTA088WRZZ Oven lamp (Interchangeable) for production use 1--
1- 9 RMOTDA253WRZZ Turntable motor 1 AV
1- 9 RMOTDA173WRE0 Turntable motor (Interchangeable) 1 AX
1- 9 RMOTDA230WRE0 Turntable motor (Interchangeable) 1 AS
1-10 RTRN-A709WRZZ Power transformer 1 BM
1-11 RV-MZA295WRE0 Magnetron 1 BF
1-12 FPWBFA353WRKZ Noise filter 1 AS
1-13 QFS-CA026WRZZ Fuse F10A 1 AH
1-14 QFS-IA009WRZZ High voltage fuse 0.75A 1 AS
CABINET PARTS
2- 1 GCABUA883WRPZ Outer case cabinet 1 BF
2- 2 FDAI-A269WRYZ Bottom plate 1 AW
2- 3 GLEGPA074WRE0 Foot 4 AC
CONTROL PANEL PARTS
3- 1 DPWBFC433WRKZ Control unit assembly 1 BG
3- 2 FPNLCB827WRKZ Control panel frame with key unit 1 BB
3- 2-1 FUNTKB152WREZ Key unit 1 AX
3- 3 JBTN-B236WRFZ Open button 1 AH
3- 4 MSPRCA050WRE0 Button spring 1 AB
3- 5 XEPSD30P08XS0 Screw : 3mm x 8mm 5 AA
OVEN PARTS
4- 1 PHOK-A131WRFZ Latch hook 1 AL
4- 2 LBNDKA163WRPZ Capacitor holder 1 AK
4- 3 NFANJA020WRE0 Fan blade 1 AG
4- 4 FOVN-A536WRTZ Oven cavity 1 BF
4- 5 MLEVPA233WRF0 Switch lever 1 AG
4- 6 GCOVHA470WRFZ Cover 1 AG
4- 7 PCOVPA394WREZ Waveguide cover 1 AK
4- 8 PDUC-A833WRPZ Air duct 1 AM
4- 9 PDUC-A853WRWZ Fan duct 1 AP
4-10 PPACGA176WREZ TTM packing 1 AC
4-11 PCUSGA399WRE0 Cushion 1 AF
4-12 PCUSUA278WRP0 Cushion 4 AB
4-13 PCUSUA235WRP0 Cushion 1 AE
4-14 PCUSGA614WRPZ Cushion 1 AE
4-15 PCUSGA615WRPZ Cushion 1 AE
4-16 MROD-A019WREZ Chassis support 1 AN
4-17 PCUSGA339WRP0 Cushion 1 AG
4-18 PCUSGA620WRPZ Cushion 1 AF
4-19 PSPAJA007WRFZ Spacer 1 AF
DOOR PARTS
5- 1 FDORFA364WRTZ Door panel 1 AS
5- 2 PSHEPA382WRE0 Sealer film 1 AH
5- 3 GWAKPA887WRFZ Door frame 1 AX
