R-370EK
R-370ES
*
*
*
*
∆
*
∆
*
∆
∆
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 FACCDA085WREZ Power supply cord 1 AQ
1- 2 QFSHDA024WRZZ Fuse holder 1 AG
1- 3 QSW-MA137WRE0 Primary interlock switch / door sensing switch 2 AH
1- 4 FFS-BA023WRK0
Monitor fuse 20A and monitor switch (AM51620C53Y1) assembly 1AS
1- 5 RTHM-A116WRE0 Thermal cut-out 125 deg. C (MG) 1 AK
1- 6 FH-DZA100WRKZ High voltage rectifier assembly 1 AQ
1- 7 RC-QZA211WRE0 High voltage capacitor 1 AV
1- 7 RC-QZA286WRZZ High voltage capacitor (Interchangeable) 1 AV
1- 8 RMOTEA400WRZZ Fan motor 1 AX
1- 9 RTRN-A638WRZZ Power transformer 1 BP
1-10 RV-MZA288WRE0 Magnetron 1 BK
1-10 RV-MZA308WRZZ Magnetron (Interchangeable) 1 BL
1-11 RLMPTA082WRZZ Oven lamp 1 AL
1-12 RMOTDA186WRE0 Turntable motor 1 AQ
1-12 RMOTDA211WRE0 Turntable motor (Interchangeable) 1 AS
1-13 RTHM-A123WRZZ Thermal cut-out 125 deg. C (OVEN) 1 AK
1-14 FDTCTA212WRKZ AH sensor 1 AX
CABINET PARTS
2- 1 GDAI-A335WRWZ Base plate 1 AW
2- 2 GLEGPA087WRFZ Front leg 1 AK
2- 3 GLEGPA081WRFZ Leg 1 AC
2- 4 GCABUA803WRPZ Outer case cabinet [R-370ES] 1 BD
2- 4 GCABUA812WRPZ Outer case cabinet [R-370EK] 1 BD
2- 5 GCOVAA291WRFZ Harness cover 1 AH
POWER UNIT PARTS
3- 1 DPWBFC179WRUZ Power unit 1 BC
3- 1A QCNCMA431DRE0 2-pin connector (CN-B) 1 AC
3- 1B QCNCMA470DRZZ 9-pin connector (CN-C) 1 AF
3- 1C QCNCMA237DRE0 3-pin connector (CN-F) 1 AD
C1 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C2 VCEAB31VW108M Capacitor 1000 uF 35V 1 AF
C3 VCEAB31VW106M Capacitor 10 uF 35V 1 AA
C12 VCEAB31VW106M Capacitor 10 uF 35V 1 AA
C50-51 RC-KZA087DRE0 Capacitor 0.1 uF 50V 2 AA
D1-4 RH-DZA006PRE0 Diode (1N4002) 4 AD
D20-22 VHD1SS270A/-1 Diode (1SS270A) 3 AA
D40 VHD1SS270A/-1 Diode (1SS270A) 1 AA
IC2 VHIBA4558//-6 IC (BA4558) 1 AK
Q1 VS2SB1238//-3 Transistor (2SB1238) 1 AA
Q21 VSDTD143ES/-3 Transistor (DTD143ES) 1 AC
Q22 VSDTA143ES/1B Transistor (DTA143ES) 1 AA
R1 VRD-B12EF242J Resistor 2.4k ohm 1/4W 1 AA
R2 VRS-B13AA331J Resistor 330 ohm 1W 1 AA
R4 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
R50 VRS-B13AA331J Resistor 330 ohm 1W 1 AA
R51 RR-DZA285DRZZ Resistor 3.32k ohm ±0.5% 1/4W 1 AC
R52 RR-DZA286DRZZ Resistor 3.57k ohm ±0.5% 1/4W 1 AC
R53 VRN-B12EK182F Resistor 1.8k ohm ±1.0% 1/4W 1 AA
R54 VRN-B12EK364F Resistor 360k ohm ±1.0% 1/4W 1 AA
RY1 RRLY-A076DRE0 Relay (OMIF-S-124LM) 1 AK
RY2 RRLY-A113DRE0 Relay (DU24D1-1P(M)-R) 1 AM
SP1 RALM-A014DRE0 Buzzer (PKM22EPT) 1 AG
T1 RTRNPA111DRE0 Transformer 1 AP
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
ZD1 VHEHZ161///-1 Zener diode (HZ16-1) 1 AA
OVEN PARTS
4- 1 PHOK-A118WRFZ Latch hook 1 AH
4- 2 LBNDKA099WRW0 Capacitor holder 1 AD
4- 3 PDUC-A772WRWZ Fan duct 1 AN
4- 4 NFANJA047WREZ Fan blade 1 AL
4- 5 PPACGA084WRF0 TTM packing 1 AE
4- 6 ************* Oven cavity (Not a replaceable part) 1--
4- 7 GCOVHA423WRFZ Choke cover 1 AL
4- 8 LANGQA531WRWZ Lamp angle 1 AP
