Sharp R-370EK - Detailed Parts List; Electric, Cabinet, and Power Unit Parts Listings

38
R-370EK
R-370ES
∆
∆
∆
∆
*
REF. NO. PART NO. DESCRIPTION Q'TY CODE
4- 9 PCOVPA361WREZ Waveguide cover 1 AD
4-10 LANG-A084WRFZ Separate angle A 1 AG
4-11 LANG-A085WRFZ Separate angle B 1 AG
4-12 LANG-A086WRFZ Separate angle C 1 AG
4-13 PCLI-A002WREZ PC support clip 2 AD
4-14 FANG-A013WRYZ Magnetron duct assembly 1 AP
4-15 LANGFA200WRPZ Support angle 1 AD
4-16 NCPL-A053WRFZ Coupling 1 AE
4-17 PCUSUA571WRPZ Cushion 1 AH
4-18 PDUC-A775WRTZ Exhaust duct 1 AP
4-19 PPACGA181WREZ Cushion 1 AH
4-20 PPACGA182WREZ Cushion 1 AC
4-21 PCUSUA573WRPZ Cushion 1 AC
4-22 PCUSUA313WRP0 Cushion 1 AF
4-23 PCUSUA578WRPZ Cushion 1 AG
4-24 PCUSUA577WRPZ Cushion 1 AC
4-25 PCUSGA561WREZ Cushion 1 AC
4-26 PCUSUA583WRPZ Cushion 1 AG
4-27 PCUSUA375WRP0 Cushion 1 AH
4-28 PCUSGA560WREZ Cushion 2 AB
4-29 PCUSUA157WRP0 Cushion 1 AC
4-30 PCUSGA563WREZ Cushion 1 AH
4-31 PCUSGA564WREZ Cushion 1 AH
DOOR PARTS
5- 1 FDORFA347WRTZ Door panel 1 AX
5- 2 PSHEPA775WREZ Sealer film 1 AH
5- 3 FWAKPA316WRKZ Door frame assembly [R-370ES] 1 BF
5- 3 FWAKPA318WRKZ Door frame assembly [R-370EK] 1 BF
5-3-1 FUNTKB060WREZ Key unit 1 AV
5-3-2 HPNL-A762WRRZ Door screen 1 AU
5- 4 LSTPPA193WRFZ Latch head 1 AE
5- 5 MSPRTA202WREZ Latch spring 1 AD
5- 6 DPWBFC176WRKZ CPU unit 1 BD
5- 7 LHLD-A236WRFZ LCD holder 1 AC
5- 8 PSHEPA786WREZ LED sheet 1 BB
5- 9 FW-VZA272DREZ 9-pin wire harness 1 AL
5-10 PCOVPA372WRWZ PWB cover 1 AF
5-11 PCUSUA567WRPZ Cushion 1 AE
5-12 XEPSD38P08000 Screw : 3.8mm x 8mm 4 AA
5-13 XEPSD30P08XS0 Screw : 3mm x 8mm 3 AA
5-14 LHLD-A237WRFZ Light guide 1 AL
MISCELLANEOUS
6- 1 FROLPA079WRK0 Turntable support 1 AP
6- 2 NTNT-A079WRF0 Turntable tray 1 AR
6- 3 FW-VZB827WREZ Main wire harness 1 AW
6- 4 QW-QZA242WRZZ High voltage wire B 1 AF
6- 5 TCAUAA265WRRZ DHHS caution label 1 AC
6- 6 TCAUAA254WRR0 Monitor caution label 1 AC
6- 7 TINSEA888WRRZ Instruction book 1 AF
6- 8 FW-VZB828WREZ Switch harness 1 AK
6-12 FW-VZB802WREZ T.T. motor harness 1 AF
SCREWS,NUTS AND WASHERS
7- 1 XHPSD40P08K00 Screw : 4mm x 8mm 8 AA
7- 2 XHPSD40P08000 Screw : 4mm x 8mm 1 AA
7- 3 XOTSD40P08000 Screw : 4mm x 8mm 6 AA
7- 4 LX-CZA073WRE0 Special screw 1 AC
7- 5 XOTSD40P12000 Screw : 4mm x 12mm 2 AA
7- 6 XHPSD30P08XS0 Screw : 3mm x 8mm 2 AB
7- 7 XHTSD40P08RV0 Screw : 4mm x 8mm 9 AA
7- 8 LX-CZA070WRE0 Special screw (Torx tamper proof screw) 2 AC
7- 9 LX-CZ0052WRE0 Special screw 2 AA
7-10 XHPSD30P06000 Screw : 3mm x 6mm 1 AA
7-11 XHTSD40P08000 Screw : 4mm x 8mm 4 AA
7-12 XHTSD40P12RV0 Screw : 4mm x 12mm 1 AA
7-13 XOTSD40P12RV0 Screw : 4mm x 12mm 7 AA
7-14 XOTSE40P08000 Screw : 4mm x 8mm [R-370ES] 2 AA
7-14 XOTSF40P08000 Screw : 4mm x 8mm [R-370EK] 2 AA
7-15 LX-EZA060WREZ Special screw 4 AA
7-16 XOTSD40P12000 Screw : 4mm x 12mm 1 AA
7-17 XHBWW30P08000 Screw : 3mm x 8mm 2 AB
