Sharp SD-NX10

SD-NX10
– 14 –
Figure 14-1
Figure 14-2
Figure 14-4
Figure 14-3
(D1)x2
ø3x8mm
(D1)x1
ø3x10mm
(D1)x3
ø3x8mm
(E2)x1
(E2)x1
(E2)x1
(E2)x1
(D2)x1
(E1)x2
ø3x8mm
Power
PWB
Power
PWB
Terminal
PWB
Rear
Panel
1-Bit Amp.
Unit
Power Trans
PWB
(G1)x1
ø3x10mm
(G1)x1
ø3x8mm
(F1)x2
ø3x8mm
(G2)x2
(F2)x2
Power
PWB
Terminal
PWB
Power LED
PWB
Main Chassis
Power Trans
PWB
Power PWB
Terminal
PWB
(H1)x2
ø3x8mm
(H1)x1
ø3x6mm
(H1)x1
ø3x6mm
(H1)x1
ø3x6mm
(H1)x1
ø3x8mm
(H1)x4
ø3x8mm
(H1)x1
ø3x6mm
(H1)x1
ø3x8mm
(H3)x1
(H2)x1
Washer
Washer
Shield
Cover
(J1)x4
ø3x10mm
1-Bit Amp.
PWB
Be careful of the
silicon grease.
1 Woofer 1. Leg Cushion ........ (A1) x4 14-5
2. Screw .................. (A2) x4
3. Top Cover ...........(A3) x1
4. Front Panel ......... (A4) x1 14-6
5. Screw .................. (A5) x8
2 Tweeter 1. Screw .................. (B1) x4 14-6
STEP REMOVAL
PROCEDURE
FIGURE
CP-NX10
Figure 14-5
Figure 14-6
(A2)x4
ø4x16mm
(A1)x4
Screwdriver
(A3)x1
Front Panel
Top Cover
Leg Cabinet
(A5)x4
ø4x40mm
(A5)x4
ø4x40mm
(B1)x4
ø4x12mm
Woofer
Tweeter
(A4)x1
