16
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
(2) Forming sensor of Damper thermostat
(3) Setting of C-box base, Damper thermostat, R-air guider A and R-air guider B
R-air guider A
Bend the senser
tube of Damper thermostat
Stick thermo.
cap. sealer
Less than 130
Damper
thermostat
3
±1
5
±1
Less than 12
25
±2
NOTE
Minimum bending radius is R5.
There should be no gas leak by reforming of sensor tube.
Paper tape (40 x 100)
Start
A-sealer RC-duct
Overlap
BB
Overlap
C-box
base
A-sealer
RC-box
Start
datum
A-sealer
RC-duct
datum
A-sealer
RC-box
SEC. BB
C-box base
A sealer air guid. C
(The back of C-box base)
Damper thermostat
C-box base
R-air guider B
Screw
Fix with claw
A-sealer air guid. D
