17
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
(4) Fixing of Lamp socket, Defrost timer
(5) Fixing of R-Cbox cover
2
±1
4
±1
WARNING
DISCONNECT AC PLUG
FROM SUPPLY BEFORE
REPLACING THE LAMP
BULB.
LAMP RATING
240V. 10W
Stick Warning label
Set R-temp. control knob
Lamp
socket
Lamp
R-Cbox cover
Connect
D timer
lead ass'y
Screw
SKY-BLUE
Insert Pin No.6
BROWN
Insert Pin No.7
Defrost timer
6
7
