SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
SJ-48G SJ-48G SJ-48G
SJ-D48G SJ-D48G SJ-D48G
-GY -BE -BL
REPLACEMENT PARTS LIST(SJ-48G/SJ-D48G)
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 RTHM-A057CBE0 F-thermostat 1 1 1 BA
1- 1 RTHM-A063CBE0 F-thermostat(Thailand only) 1 1 1 AX
1- 2 RSTT-A105CBE0 Starting relay
(220/230/240V 50Hz region) 1 1 1 AN
1- 2 RSTT-A110CBE0 Starting relay
(200/220V 50Hz region,220V 60Hz region) 1 - - AN
1- 3 QSWTDA035CBE0 Defrost timer 1 1 1 BB
1- 4 PDMP-A025CBE0 Damper thermostat 1 1 1 AZ
1- 4 PDMP-A028CBE0 Damper thermostat(Thailand only) 1 1 1 AY
1- 5 FTHM-A012CBK0 Defrost thermo.ass’y 1 1 1 AQ
1- 6 RMOTRA030CBE0 Fan motor 1 1 1 AZ
1- 7 QSOCAA037CBE0 Lamp socket 1 1 1 AM
1- 8 RLMP-001ECBE0 Lamp 1 1 1 AH
1- 9 QACC-A096CBE0 Source cord(Plug type BF) 1 1 1 AX
1- 9 QACC-A101CBE0 Source cord(Plug type C-2) 1 1 1 AN
1- 9 QACC-A095CBE0 Source cord(Plug type A-1) 1 1 1 AM
1-10 QSW-PA056CBEA Door switch 1 1 1 AP
1-11 RHOG-A091CBE0 Protector
(220/230/240V 50Hz region) 1 1 1 AN
1-11 RHOG-A092CBE0 Protector
(200/220V 50Hz region,220V 60Hz region) 1 - - AN
1-15 RC-EZA124CBE0 Running capacitor 1 1 1 AX
1-16 FW-VZA108CBE0 Earth wire(For 3P. plug) 1 1 1 AE
1-17 FFS-TA036CBK0 Fuse ass’y 1 1 1 AN
1-19 FW-VZA109CBE0 D timer lead ass’y 1 1 1 AN
1-20 FW-VZA110CBE0 Lead EV-cover ass’y 1 1 1 AP
1-21 FHETBA082CBE0 Def. heater ass’y 1 1 1
(SJ-D48G,220/2330/240V 50Hz region220V 60Hz region)
1-21 FHETBA087CBE0 Def. heater ass’y (SJ-D48G,200/220V 50Hz region) 1 - - BK
1-21 FHETBA072CBE0 Def. heater ass’y(SJ-48G) 1 1 1 BD
1-22 QCNW-A634CBE0 Relay wire G(For 3P. plug) 1 1 1 AE
1-23 QCNW-A635CBE0 Relay wire B 1 1 1 AE
1-24 QCNW-A636CBE0 Relay wire BR 1 1 1 AE
1-25 QTAN-A032CBE0 Terminal block 1 1 1 AE
MECHANICAL PARTS
2-1 LSTPPA078CBFA Back spacer 1 1 1 AD
2-2 JKNB-A036CBFA F-temp. control knob 1 1 1 AL
2-4 LPLTMA404CBE0 FL plate AL. 1 1 1 AD
2- 7 FLEGPA045CBK0 Leg holder L ass’y 1 1 1 AQ
2- 7-1 FAJS-A009CBK0 Adjustable leg ass’y 2 2 2 AD
2- 7-2 LHLD-A354CBM0 Leg holder L 1 1 1 AE
2- 8 FLEGPA046CBK0 Leg holder R ass’y 1 1 1 AQ
2- 8-2 LHLD-A355CBM0 Leg holder R 1 1 1 AE
2-11 PSPAVA074CBEA Bottom hinge spacer 1 1 1 AD
2-13 DHNG-A274CBM0 Upper hinge ass’y 1 1 1 AK
2-14 DHNG-A275CBM0 Bottom hinge R ass’y 1 1 1 AK
2-15 DHNG-A276CBK0 C-hinge RD ass’y 1 1 1 AN
2-15-1 PSPAVA075CBEA Center hinge spacer 1 1 1 AD
2-16 GCOV-A141CBFA E.V cover 1 1 1 AD
2-17 LCRA-A010CBE0 Fan clamp 1 1 1 AD
2-19 LHLD-A245CBF0 Motor cushion 2 2 2 AF
2-20 NFANPA011CBF0 Propeller fan100 1 1 1 AD
2-21 PSEL-B128CBE0 E.V cover sealer A 1 1 1 AD
2-22 PSEL-B129CBE0 E.V cover sealer B 1 1 1 AD
2-23 PSEL-A415CBE0 E.V cover sealer C 1 1 1 AC
2-24 PCOVPA164CBFA Terminal cover(Singapore, Malaysia) 1 1 1 AE
2-24 PCOVPA175CBFA Terminal cover 1 1 1 AF
2-26 PCOV-A151CBFA Lamp cover 1 1 1 AF
2-27 GCOVPA067CBRA R-Cbox cover 1 1 1 AE
2-28 HGRL-A133CBRA Fan louver 1 1 1 AT
2-29 GCOV-A140CBFA Upper hinge cover 1 - - AE
2-29 GCOV-A140CBFC Upper hinge cover - 1 - AE
2-29 GCOV-A140CBFF Upper hinge cover - - 1 AE
2-31 JKNB-A033CBFA R-temp. control knob 1 1 1 AD
2-33 LRALPA114CBFA C-case rail L 1 1 1 AE
2-34 LRALPA115CBFA C-case rail R 1 1 1 AE
2-36 PCAP-A006CBFK Screw cover - 1 - AD
2-36 PCAP-A006CBFL Screw cover 1 - - AB
2-36 PCAP-A006CBFM Screw cover - - 1 AB
2-38 PGID-A119CBF0 R-air guider A 1 1 1 AH
2-39 LFRM-A202CBFA C-box base 1 1 1 AK
2-40 PFPFPA809CBF0 RA-insulation 1 1 1 AD
