8
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
DESTINATION: Z
Items SJ-48G, SJ-D48G SJ-51G, SJ-D51G, SJ-55G, SJ-D55G
Source 220V 50/60Hz
Climate class T
Thermostat Type: MM1-8025 ON: –17±5˚C OFF: –22±1.5˚C(at normal notch)
Damper thermostat Type: MM1-6129
Baffle opened 1.5˚C(at normal notch)
Baffle closed –3±1.5˚C
Timer Type: TMDF904FD2, Integration type
Cycle 10hours 50 min., Working time about 4min. 20sec. 50Hz
Fuse ass'y Thermo. fuse Type: SF70E 250V 10A Working temp. 70±2˚C
or MTG4A50072 250V 10A Working temp. 72±2˚C
Defrost thermostat Type: US602S 250V 8A OPEN 10±3˚C CLOSE 1±3˚C
Door switch 3 terminals push-button 250V 0.25A
Lamp socket 250V 1A E-12(HARD PLASTIC BODY TYPE)
Lamp 240V 10W E-12
Fan motor Type: MH15SAF-TJA7 200/240V 50Hz 0.8W
Compressor Type: GL-99BL
50/60Hz(OIL COOLING)
Cooling capacity 244W/279W
Main coil 6.68Ω
Aux. coil 9.30Ω(at 20˚C)
Terminal
Starting relay PTC/UH-3003 14Ω 350V
Overload relay
(Protector)
4TM306NFBYY OFF 120˚C ON 61˚C
Running capacitor 6µF / 400V
Defrost heater 220V 137W 353Ω
Aux. coil
Common
Main coil
