• Buzzer: =0.5 sec ON/0.5 sec OFF, =2 sec ON/0.5 sec OFF
No. Status Buzzer LED
Display
Content
Correspon-
dance
method
- No defects None - - - -
1 F-thermistor system defect
01
Defect of each thermistor, short circuit/wire breakage
of thermistor wiring and defect of main PWB
→[1]
2 R-thermistor system defect
02
→[2]
3 DEF-thermistor system defect
03
→[3]
4
Outside temperature-thermistor sys-
tem defect
04
→[4]
5 Defrost defect
07
Wire breakage of fuse, defrost heater, defect of main
PWB
(120-minute defrosting has been occurred continu-
ously 2 times within the past 48 hours.)
→[5]
6 Fan motor system defect
08
Defect of wiring / main PWB
(When fan motor is ON, over current or no current is
detected.)
→[6]
7
Ionizer (Plasmacluster) system
defect
11
Defect of wiring / main PWB
(When Plasmacluster is ON, over current or no current
is detected.)
→[7]
8 LED Display communication defect
12
Short circuit/wire breakage of wiring and defect of LED
or main PWB (Communication with LED PWB has
been abnormal over 3 times within the past 48 hours.)
→[8]
9 F-thermistor system defect history
61
Defect of thermistor system has been occurred over 1
minute continuously within the past 48 hours.
→[1]
10 R-thermistor system defect history
62
→[2]
11 DEF-thermistor system defect history
63
→[3]
12
Outside temperature-thermistor
system defect history
64
→[4]
13 F fan motor system defect history
66
Defect of fan motor has been occurred over 3 times
continuously within the past 48 hours.
→[6]
14
Ionizer (Plasmacluster) electrifying
defect history
72
Defect of Ionizer (Plasmacluster) electrifying has been
occurred over 3 times continuously within the past 48
hours.
→[7]
15 F-room high temperature history
76
Temperature of F-thermistor has been reached over
-10°C continuously for 6 hours or more within the past
48 hours. (except right after the installation)
→[1]
16 R-room high temperature history
77
Temperature of R-thermistor has been reached over
+10°
C continuously for 6 hours or more within the past
48 hours. (except right after the installation)
→[2]
