SJPT55RHS
9 – 2
4) Set Fan motor, F-thermistor, Def-thermistor, Fuse ass'y in the EV cover and stick Al tape. (Figure A-5)
Figure A-5
5) Set the Deodorizer to the Fan louver.(Only for SJ-PT51R, PT55R)
Figure A-6
F fan motor
Def-thermistor
F-thermistor
STICK AL TAPE
SEC. AA
AL TAPE (T40 *W30*52L)
Fuse ass’y
Fan louver
Deodorizer
