33
SMD2470AHAUPDATE
PARTS LIST
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRICAL PARTS
1-1 FC-QZA637WRKZ HVC ASSY 1 AM
1-2 DPWBFB235MRU8 PSU- Drawer 1 BA
1-3 DPWB-B383DRKZ SW PSU- Drawer 1 BE
1-4 FACCDA129WREZ POWER SUPPLY CORD 1 AP
1-5 FDTCTA234WRKZ SENSOR ASSY 1 AP
1-6 FMOTEB062MRK0 FAN MOTOR ASSY 1 AD
1-7 FPWBFA512WRKZ Noise Filter Unit 1 AN
1-8 FFS-BA018/KIT MONITOR FUSE (V-5220Q) WITH FUSE (20A) ASSEMBLY 1 AF
1-9 RLMPTA099WRZZ OVEN LAMP WITH SOCKET 1 AE
1-10 RMOTDA283WRZZ STIRRER MOTOR 1 AM
1-11 QFS-TA013WRE0 OVEN/MG DM FUSE 2 AH
1-12 RTRN-B101MRE0 TRANSFORMER 1 BD
1-13 RV-MZA365WRZZ MAGNETRON 1 AZ
1-14 FW-VZC496WREZ DRAWER HARNESS 1 BC
1-15 QSW-MA168WRZZ Secondary interlock switch / Door sensing switch 2 AE
1-16 FANGTB020MRK1 AUTO DRAWER GEAR ASSY 1 BL
CABINET PARTS
2-1 GCABUB314WRPZ OUTER CASE CABINET 1 AM
2-2 LANGQA830WRPZ AC CORD MOUNT ANGLE 1 AM
2-3 LANGTB363MRT0A SIDE ANGLE L 1 AK
2-4 LANGTB364MRT0A SIDE ANGLE R 1 AK
2-5 LBSHCA014WRE0 CORD BUSHING 1 AB
2-6 PCOVPA670WRPZ LATCH COVER 2 AB
CONTROL PANEL PARTS
3-1 DPWBFB240MRU8 CPU- Drawer 1 AY
3-2 DPNLCB227MRK0 HIDDEN CONTROL PANEL HINGE ASSY 1 BQ
3-3 PMAG-B002MRE0A MAGNETIC STRIP 1 AD
3-4 PMAG-B003MRE0A ROUND MAGNET 2 AF
3-5 XEPS730P10XS0 M3 X 10 SCREW - STEEL P-TIGHT 2 AC
3-6 LX-CZB066MRE0 Screw- #4 x 1/3# Flathead SS 6 AA
3-7 LX-WZB040MRE0 O-Ring- 4mmID Rubber 2 AA
3-8 PCUSGB116MRP0 CUSHIONS 4 AB
3-9 FHNG-B058MRY0 CP HINGE ASSY LEFT 1 AH
3-10 FHNG-B057MRY0 CP HINGE ASSY RIGHT 1 AH
3-11 LX-CZB060MRE0 Screw- #8-18 3/8" PHILLIPS PAN 8 AA
3-12 LHLD-B053MRF0A C/P BTM MOUNT INSERT 1 AK
3-13 CPNLCB924MRK0 CONTROL PANEL ASSY 1 BP
3-14 HDECAC042MRQ0 C/P DECORATION 1 AZ
3-15 LX-BZB073MRE0 M4 FLAT HEAD SCREW 2 AA
3-16 PCUSUB130MRP0 EPDM CUSHION 1 AB
OVEN PARTS
4-1 LSTPPA332WRFZ DOOR STOPPER 2 AK
4-2 FGLSPB005MRY0 OVEN TRAY ASSY 1 BH
4-3 ************* CAVITY ASSEMBLY (not replaceable parts) 1 -
4-4 FPLT-B002MRY0A ANTENNA ASSY 1 AS
4-5 GCABDA205WRWZ BACKPLATE 1 AM
4-6 GCOVHB066MRF0 DOOR SUPPORT COVER 2 AM
4-7 GDAI-A474WRWZ BASE PLATE 1 AX
4-8 LANGTA590WRTZ DOOR SUPPORT ANGLE A 2 AN
4-9 LANGTA591WRTZ DOOR SUPPORT ANGLE B 1 AN
4-10 LBNDKA186WRPZ HVC BAND 1 AB
4-11 LHLD-A352WRFZ PSU HOLDER 1 AH
4-12 LHLD-A387WRFZ SW PSU HOLDER 1 AD
4-13 MSLIFB006MRE0 SLIDE RAIL 3 AY
4-14 NGERRB006MRF0 RACK GEAR 1 AP
4-15 PCLICA044WREZ CANOE CLIP 4 AV
4-16 LANGTB380MRP0 C/P REAR COVER 1 AG
4-17 PCOVPA597WREZ ANTENNA COVER 1 AB
4-18 PCOVPA590WRPZ OVEN LAMP COVER 1 AM
4-19 PCUSGA807WRPZ INLET CUSHION 2 AB
4-20 PCUSGA808WRPZ HVT CUSHION 1 AC
4-21 PCUSGA809WRPZ EXHAUST DUCT CUSHION 1 AR
To Next Page
