Sharp SMO1854DS Service Manual

30
PCB COMPONENT NO.
NO PART NAME SYMBOL PART CODE SPECIFICATION Q'TY
53 R CHIP R45 9KC40H08-0043900 1/10W 357K 2012, 1% 1
54 R CHIP R46-47 9KC40H08-0044500 1/10W 200 2012, J 2
55 R CHIP R9 R49 R25 9KCHRFT473JCB 1/10W 47K OHM J 2012 3
56 R CHIP R51 9KC40H08-0044100 1/10W 301K 2012, 1% 1
57 R CHIP R52 9KC40H08-0042900 1/10W 150K 2012, 1% 1
58 R CHIP R53 9KC40H08-0044400 1/10W 75K 2012, 1% 1
59 R CHIP R54 9KCHRFT105JCB 1/10W 1M OHM J 2012 1
60 R CHIP R23 R36 9KCHRFT102JCB 1/10W 1K OHM J 2012 2
61 R CARBON FILM R18 R19 R24 9KCRD-AZ102J- 1/6 1K OHM J 3
62 R CHIP R37 9KC40H08-0000700 1/4W 1K OHM J 3216 1
63 R CHIP R59 R69 9KC40H08-0020400 2M OHM 1/4W 3216 2
64 R CHIP R61-68 9KCHRFT471JCB 1/10 470 OHM J 2012 8
65 R CARBON FILM R60 9KC40R01-0001300 1/2 1M OHM J 1
66 RESISTOR M-OXIDE FILM R70 9KC40R01-0026900 1W 100K OHM J 1
67 RESISTOR METAL FILM R71 9KCRN-4Z681F- 1/4 680 OHM F 1
68 R METAL FILM R72 9KCRN-4Y102F- 1/4 1K OHM F 1
69 R METAL FILM R73 9KCRN-4K303F- 30K OH 1/4W F 1
70 R CHIP R74 9KCHRFT203JCB 1/10W 20K OHM J 2012 1
71 R CHIP R75 9KCHRFT472JCB 1/10W 4.7K OHM J 2012 1
72 R CHIP R76 9KCHRF8512JEA 5.1K OHM 1/8W 3216 J 1
73 R CARBON FILM R77 9KCRS01F104J- 1W 100K OHM J 1
74 R CHIP R78 9KCHRFT123J1P 1/10W 12K OHM J 2012 1
75 R CHIP R79 9KCHRFT6R8JCB 1/10W 6.8 OHM J 2012 1
76 R CHIP R80 R83 R88 9KCHRFT103JCB 1/10W 10K OHM J 2012 3
77 R CHIP R82 9KCHRFT105JCB 1/10W 1M OHM J 2012 1
78 R CHIP R50 9KC40H08-0044200 1/10W 604K 2012, 1% 1
79 R CHIP R26-27 9KCHRFT103J1P 1/10W 10K OHM J 2012, 1% 2
80 R CHIP R12 9KCHRFT102JCB 1/10W 1K OHM J 2012 1
81 IC REGULATOR IC8 9KC1KA431AZ-- KA431AZ 1% TO-92 IC REGULATOR 1
82 IC REGULATOR VL1 9KC1CPMC7805C MC7805C(S/S) 1
83 IC REGULATOR VL2 9KC1K1A7812AP KIA7812AP 1
84 SW RELAY RY1 9KC5SC0101171 SFK-112DM 1
85 SW RELAY RY4-6 RY9,RY11 9KC5SC0101350 PCJ-112D3M 5
86 SW RELAY RY2 9KC5SC0101121 G5G-1A 1C 1P DC12V 1
87 SW RELAY RY7-8 9KC5SC0101906 G5Q-1 DC12V 2
88 IC RESET IC3 9KC1K1A7033AP KIA7033AP 1
89 RESONATOR CERA CR1 9KC40508-0000700 CSTLS8M00G53-BO 1
90 R ARRAY RA1 9KCRA-87X103J 7P(6) 1/4 10K OHM J 1
91 TR CHIP Q3 Q6,Q8-9 Q15-18 Q20
Q24-25
9KC40H09-0000700 KRC246S 12
92 TR CHIP Q26-30 9KCTKTRC226SB KRA226S 7
93 TR Q19 9KCTZTA1266Y- KTA1266Y- (2SA1980NYATPF) 1
94 TR CHIP Q2 9KC40H09-0000200 KTC3265-Y 1
95 TR CHIP Q1 Q4 9KCTKTA1298YB KTA1298Y 2
96 VARISTOR VS1 9KCDSVC471D14 SVC471D14A(BULK) 1
97 DIODE ZENER ZD1 9KCDZUZ4R7BSB MTZ J 4.7B 1
98 DIODE ZENER ZD2 9KC40D03-0009200 1N5254B (0.5W / 27V / DO-41) 1
99 BOARD MWO PCB BOARD 9KC40303-0114400 M381(CEM) 1

Sharp SMO1854DS Specifications

General

Style	over the range
Color	stainless steel
Total Capacity	1.8 cu. ft.
Convection	no
Power Levels	10
Fan Speeds	3
Venting Type	non ducted
Sensor Cooking	yes
Quick Start	yes (1-6 minutes)
Control Type	touch control
Child Lock	yes
Timer	yes
Interior Light	led; yes
Microwave Power	1, 100 watts

Weight and Dimensions

Depth	15 9/10 inch
Height	16 3/10 inch
Width	29 9/10 inch
