Sharp SMO1854DS Service Manual

29
3. PCB COMPONENT NO.
NO PART NAME SYMBOL PART CODE SPECIFICATION Q'TY
1 LED DISPLAY DP1 9KC40D05-0033700 DGD-D5812B-21 1
2 BUZZER BZ1 9KC3515600100 BM-20K (BUJEON) 1
3 DIODE BD1 9KCDD4SB80--- D4SB80 (7100) 1
4 C CHIP CERA C1-2 C7-10 C12-14 C16-19
C25
9KCHCFK104ZCB Y5V 50V 0.1MF Z 2012 14
5 C CERA C15 9KCCCXF3B102K 1KV 1000PF 1
7 C CHIP CERA C20 C23 9KCHCBH104KCA 0.1MF 25V 2012 X7R K 2
8 C CERA AC C22 C21 9KCCH1BEE102M U/C/V 2.5KV 1000PF M 2
9 C CHIP CERA C24 C11 C26 9KCHCBK102KCA 50V X7R 1000PF K 2012 3
10 CAPACITOR LINE ACROSS XC1-2 9KC40C01-0036700 AC275V 0.47MF CMPP 2
11 C ELECTRO EC1 9KCCEXE1H229A 50V RS 2.2MF (5X11) TP 1
12 C ELECTRO EC2 9KCCEXF1E101V 25V RSS 100MF (6.3X11) TP 1
13 C ELECTRO EC3 9KCCEXF1E471V 25V 470MF 10X12.5 1
14 CAPACITOR ELECTRO EC4 9KCCEYE2H470D 500V RMU 47MF 105DEG (18X31.5) 1
15 CAPACITOR ELECTRO EC5 9KCCEYF1E102F 25V GF 1000MF 12.5X20 1
16 CAPACITOR ELECTRO EC6 9KCCEXF1E471C 25V RUS 470MF (10X16) TP 1
17 CAPACITOR ELECTRO EC7 9KCCEXF1E101C 25V RUS 100MF (6.3X11) TP 1
18 CAPACITOR ELECTRO EC8 9KCCEXF1E470C 47MF 25V (5X11) RUS TP 1
19 CAPACITOR ELECTRO EC9 EC10 9KCCEXF1H100C 50V RUS 10MF (5X11) TP 2
20 CONN FILM CN3 9KC441M367170 FCZ 254-11 1
21 CONN WAFER CN4 9KC30166M503R MOLEX 35312-0312 RED 1
22 CONN WAFER CN2 9KC3519150800 YW396-11(2468)V 1
23 CONN WAFER CN1 9KC65191-0016300 YW396-15AV 1
24 C ARRAY CA1 9KCCN6XB-102M 7P(6) 1000PF M 50V 2.54MM 1
25 DIODE D1-3 9KCDZN4004A-- KN4004A AUTO 52MM 3
26 DIODE D4-9 D14-15 D21-22 D29
D35
9KCDZN4148--- 1N4148 AUTO 52MM 12
27 DIODE CHIP D17-20 D13 D11 D25-26
D30-34
9KC40D03-0016900 1N4148WS_L1SS355T1H 14
28 DIODE D28 9KCDS3L20UP75 S3L20U(5002 P7.5MM) 1
29 DIODE D27 9KCD1N4007SMD 1N4007 SMD, M7 DIODE 1
30 DIODE CHIP D36 9KC40D03-0008800 ES1G 1A 400V SMD 1
31 DIODE D37 9KCDUF4007--- UF4007 DO-41 1000V 1A 1
32 FUSE PLASTIC F1 9KC5FWPR2022L WIDE 250V 2A TR5 382 SERIES 1
33 TRANS SMPS T1 9KC40512-0009700 WST-1407 (EE2519V) 1
34 IC OP AMP IC4 9KC1CPLM358-- LM358 (S.S) 1
35 IC POWER IC2 9KC40101-0026600 TOP265KG 1
36 IC MICOM IC1 9KC40101-0045400 ABOV FLASH(MC97F66128LB14) 1
37 IC EEPROM IC5 9KC40101-0002900 CAT24WC02W-TE13, 2K S-24CS02AFJ-
TB-GE
1
38 WIRE COPPER J1-10, J16, J17-35 9KC85801052GY 1/0.52 TIN COATING 35
39 FILTER LINE L1 9KC5P1116103B LF-1116A1 1
40 IC PHOTO COUPLER OP1-2 9KC40101-0026200 PHOTO COUPLER(PC817_HUAJING) 2
41 THERMISTOR PTC PTC1 9KCDP1390MK10 PP1AR390MK10 1
42 R CHIP R1 R6 R8 R22 R81 R85 9KCHRFT000JCB 0 OHM 2012 (JUMPER) 6
43 R CHIP R2 R3 R7 R48 R89 R87 9KC40H08-0044800 0 OHM 1/4 3216 6
44 R CHIP R13 9KCHRFT101JCB 1/10 100 OHM J 2012 1
45 R CHIP R14 R20-21 R55 R11 9KCHRFT472JCB 1/10W 4.7K OHM J 2012 5
46 R CHIP R15 R10 9KC40H08-0010800 1/10W 2K J 2012, 1% 3
47 R CHIP R38 9KCHRFT104JCB 1/10W 100K 2012 1
48 R CHIP R39 9KC40H08-0044100 1/10W 301K 2012, 1% 1
49 R CHIP R40-41 9KC40H08-0044000 1/10W 3.32K 2012, 1% 2
50 R CHIP R42 9KC40H08-0042900 1/10W 150K 2012, 1% 1
51 R CARBON FILM R43 9KCRD-2Z201J- 1/2 200 OHM J 1
52 R CHIP R44 9KC40H08-0044300 1/10W 1.82K 2012 1% 1

Sharp SMO1854DS Specifications

General

Style	over the range
Color	stainless steel
Total Capacity	1.8 cu. ft.
Convection	no
Power Levels	10
Fan Speeds	3
Venting Type	non ducted
Sensor Cooking	yes
Quick Start	yes (1-6 minutes)
Control Type	touch control
Child Lock	yes
Timer	yes
Interior Light	led; yes
Microwave Power	1, 100 watts

Weight and Dimensions

Depth	15 9/10 inch
Height	16 3/10 inch
Width	29 9/10 inch
