Sharp SMO1854DS Service Manual

3
SPECIFICATIONS
EXTERNAL VIEW
29.9 15.9
16.3
(Unit : in.)
1. OUTER DIMENSION
POWER SUPPLY 120V AC, 14.7 AMPS, 60Hz SINGLE PHASE WITH GROUNDING
MICROWAVE
INPUT POWER 1700 W
ENERGY OUTPUT 1100 W
FREQUENCY 2,450MHz
OUTSIDE DIMENSIONS (W x H x D) 29.9 x 16.3 x 15.9 in
CAVITY DIMENSIONS (W x H x D) 20.6 x 10.0 x 14.9 in
CAVITY VOLUME 1.8 cu.ft
NET WEIGHT APPROX. 51.1 lbs
TIMER 99 min. 99 sec.
POWER SELECTIONS 10 Levels

Sharp SMO1854DS Specifications

General

Style	over the range
Color	stainless steel
Total Capacity	1.8 cu. ft.
Convection	no
Power Levels	10
Fan Speeds	3
Venting Type	non ducted
Sensor Cooking	yes
Quick Start	yes (1-6 minutes)
Control Type	touch control
Child Lock	yes
Timer	yes
Interior Light	led; yes
Microwave Power	1, 100 watts

Weight and Dimensions

Depth	15 9/10 inch
Height	16 3/10 inch
Width	29 9/10 inch
