Select the test mode 6 (line forced drainage) in the following sequence:
“Clear” → “Manual” → “Start” → “Start” → “Open/Close door” →
“Touch key [6]” → “Start”
Set the empty water tank onto the main body
Press the Start key to start drainage
Because drainage is completed after a specified time,
press the “Cancel” key to return to the initial screen
Select the test mode 33 in the following sequence: “Cancel” → “Manual” → “Start”
→“Start” → “Open/close door” → use the “Manual heating” key or the “Return”
key to go to [33] → “Start”.
Add water into the water tank to above the “Repair” line, set the tank
to the main body, close the door and the “Start” key will blink
Press the Start key to start water supply
The engine level value is smaller than 20
(hexadecimal system)
NO
YES
Even if drainage is repeated for 5 times,
the level value is no less than 20
(hexadecimal system)
NO
YES
NO
YES
Normal
Repair the connector
Repair or replace the
water pathway (tube)
There is no disconnected
or incorrect wiring at the connecting
connector (relay board, sensor part)
of the engine water level sensor
and the pump unit
NO
YES
There is no leakage, blocking or
bending in the water line
NO
YES
Add water into the water tank to above the Repair line and set the tank to the main body. Remove the water
supply/drainage tube from the engine unit. Run “FEED ON” in the test mode and feed water into other containers
for 1 minute and then stop it by pressing “OFF”
Water supply quantity
is above 44cc
NO
YES
Pull up the engine water level sensor connecting connector from the board, inject 30cc water
into the engine and measure the resistance value of the engine water level sensor with a tester
The resistance value of the engine water
level sensor is infinitely great
NO
YES
Replacement of the pump unit
or the relay board
Replace the display
board
or the relay
board
*
Replacement of the engine unit or the harness
Repair the connector
Repair or replace the
water line (tube)
There is no disconnected
or incorrect wiring at the connecting
connector (relay board, sensor part)
of the engine water level sensor
and the pump unit
NO
YES
There is no leakage, blocking
or bending in the water line
NO
YES
Inject 30cc water into the engine and set the empty water tank to the main body.
Run “DRAIN ON” in the test mode 51 and then stop it 1 minute later by pressing “OFF”
Above 28cc in the water tank
NO
YES
Pull up the engine water level sensor connecting connector from the
board
and measure
the resistance value of the engine water level sensor with a tester
The resistance value of the engine water
level sensor is infinitely great
NO
YES
Replacement of the pump
unit or replacement of the
relay
board
Water supply is completed
and TIME (water supply time)
count stops above
30 and below 70
