Sharp SuperSteam Plus SSC3088AS User Manual

SSC3088AS
15
TEST PROCEDURES
Error record confirmation procedure
Power on/door open/close→ [Clear]→ [Manual heating]→ [Start]→ [Start]→ Door open/close operation→ Press the [Back] key 14 times to set the test mode
number at 16● [Start]
Inspection method when error occurs
1. Inspection method of water supply performance and engine liquid-level sensor performance
1) Confirm the water tank is installed
Install the water tank onto the main body and confirm its installation.
Leave the tank filled with water attached to
the main body for a while
There isn’t much water
leakage in the tank cover
NO
YES
The water tank
does not deform
NO
YES
Replacement of
the water tank
The water supply and drainage pipes
of the water tank are not damaged
NO
YES
Replacement of the water tank cover
Normal
Confirm the water supply performance and engine liquid-level sensor performance
Confirm the water supply performance and engine liquid-level sensor performance by test mode 33.
Target
Measurement
level
FEED ON: water supply starts
DRAIN ON: water drainage starts
OFF:pump stops
TANK:tank SW
ENGINE LEVEL:engine water level
TIME:water supply time
TSUYU:drip pan SW
20
TANK SW
20 00
00
ENGINE LEVEL
TIME
TSUYU
33
FEED
WATER
RESULTS IN BLUE
INDICATES GOOD
