Sharp SuperSteam Plus SSC3088AS User Manual

SSC3088AS
8
Always take caution lifting heavy products.
3. Use a minimum of 2 people to lift and remove oven.
Partially remove oven from cabinet and unplug the power
supply cord from the electrical outlet (Figure 7).
4. When removing the unit, careful not to use the outer
oven frame. Use only the Side Handles (Figure 7).
DO NOT
lift this unit
using the outer
oven frame
Side Handle (x2)
Lift point
on frame
Figure 7
2. Open the oven door and remove the 4 mounting screws from
the Mounting Bracket (Figure 6).
Figure 6
1. Open the drip tray door and remove the 2 shoulder
Figure 5
bolts/sleeve (Figure 5).
Figure 8
5. Remove 4 screws (2 each side) from the BIK Mount.
After the BIK Mount is removed, careful not to scratch
or damage (Figure 8).
BIK Mount
Screws
SUPER STEAM REMOVAL FROM CABINET
