Sharp SWB3052DS Installation Instructions

4E
OPENING DIMENSIONS
Electrical Junction
Box Location
NOTE: Junction
box may be located
in adjacent cabinet
D
C
A
B
F
E
B
A
C
D
C
A
B
F
E
E
4"
4"
4"
LETTER DESCRIPTIONS
SINGLE OVEN
UNDERCOUNTER
WITHOUT COOKTOP
SINGLE OVEN IN CABINET DOUBLE OVEN IN CABINET
A Width (cutout) 28
5
/8" (72.7 cm) 28
5
/8" (72.7 cm) 28
5
/8" (72.7 cm)
B Height (cutout) 27
1
/2" (70.0 cm) 27
1
/2" (70.0 cm) 50
1
/4" (127.6 cm)
C Depth (cutout) 24" (61.0 cm) 24" (61.0 cm) 24" (61.0 cm)
D
Top of Cutout to Bottom of Upper
Cabinet Door
N/A 1
1
/2" (3.8 cm) 1
1
/2" (3.8 cm)
E
Bottom of Cutout to Floor
(recommended)*
5
1
/4" (13.3 cm) 32" (81.3 cm) 14
3
/4" (37.5 cm)*
F
Bottom of Cutout to Top of Cabinet
Door
N/A 1
1
/2" (3.8 cm) 1
1
/2" (3.8 cm)
G Overlap of oven with sides of cutout
11
/16" (1.7 cm)
11
/16" (1.7 cm)
11
/16" (1.7 cm)
* Bottom of Cutout to Floor (acceptable) 4" to 14
3
/4" (10.2 cm to 37.5 cm)
Single Oven - Installed in Cabinet
and Installed Undercounter
Double Oven - Installed in Cabinet

Sharp SWB3052DS Specifications

General

Style	double
Color	stainless steel
Total Capacity	10 cu. ft.
Temperature Probe	yes
Microwave	no
Convection	yes
Racks	5
Control Type	touch sensor
Interior Light	yes
Delay Start	yes
Wi-Fi	no
Kitchen Timer	yes
Power Consumption	3, 600
Voltage	240 volts
Current	40

Weight and Dimensions

Depth	23 1/2 inch
Height	51 3/16 inch
Width	29 7/8 inch
