Sharp SX68JF100 - Printed Wiring Board Assemblies

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
54
SX68JF100
Ref. No. Part No. ★ Description Code
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual: electrical components having such fea-
tures are identified by "å" in the Replacement Parts Lists.
The use of a substitute replacement part which does not have the
same safety characteristics as the factory recommended replace-
ment parts shown in this service manual may create shock, fire or
other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. CODE 6. QUANTITY
★ MARK: SPARE PARTS-DELIVERY SECTION
PICTURE TUBE
å VB68QCP892X1E R Picture Tube
å DY RCiLH0205PEZZ R Deflection Yoke
å L2799 RCiLG0056PEZZ J Degaussing Coil AS
å QEARC2913PEZZ J Grounding Strap AK
PMAGF3038CEZZ R Purity Magnet AL
PMAGG3002CEZZ R Magnet AC
PSPAG0003PEZZ J Wedge AD
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
PWB-A DUNTK9859WEX2 – MAIN Unit —
PWB-B DUNTK9860WEV8 – POWER Unit —
PWB-C DUNTK9848WEV1 – CRT Unit —
PWB-D DUNTK9358WEV1 – DIG. COM. Unit —
PWB-E DUNTKA049WEV0 – CONTROL Unit —
PWB-H DUNTKA048WEV1 – SUB POWER Unit —
PWB-I DUNTK9863WEV4 – NICAM Unit —
PWB-J DUNTK9861WEV8 – VCJ Unit —
PWB-A DUNTK9859WEX2
MAIN UNIT
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED
AS AN ASSEMBLY BUT NOT INDEPENDENTLY.
å TU201 VTUVTBT6ED265 R VHF Tuner BH
INTEGRATED CIRCUITS
IC402 VHiM52055FP-1 R M52055FP AH
IC451 VHiCXA2069Q-1 R CXA2069Q AR
IC601 VHiKA7805Pi-1 J KA7805PI AE
IC602 VHiKA7805Pi-1 J KA7805PI AE
IC605 VHiKA7809Pi-1 J KA7809PI AE
IC607 VHiM51497L/-1 R M51497L AL
IC1000 RH-iX3285CEN5 R I.C.
IC1001 VHiM24C08B/-1 R M24C08-BN6 AM
IC1002 VHiPST994C/-1 R PST994C AD
IC1300 VHiTDA7482/-1 R TDA7482 AR
IC1301 VHiTDA7482/-1 R TDA7482 AR
TRANSISTORS
Q200 VS2SB709AR/-1 R 2SB709AR AC
Q201 VS2SD601AR/-1 R 2SD601AR AC
Q202 VS2SD601AR/-1 R 2SD601AR AC
Q203 VS2SB709AR/-1 R 2SB709AR AC
Q204 VS2SD601AR/-1 R 2SD601AR AC
Q351 VS2SD601AR/-1 R 2SD601AR AC
Q352 VS2SD601AR/-1 R 2SD601AR AC
Q353 VS2SD601AR/-1 R 2SD601AR AC
Q354 VS2SD601AR/-1 R 2SD601AR AC
Q406 VS2SB709AR/-1 R 2SB709AR AC
Q407 VS2SD601AR/-1 R 2SD601AR AC
Q451 VS2SD601AR/-1 R 2SD601AR AC
Q452 VS2SD601AR/-1 R 2SD601AR AC
Q453 VS2SD601AR/-1 R 2SD601AR AC
Q454 VS2SD601AR/-1 R 2SD601AR AC
Q501 VS2SD601AR/-1 R 2SD601AR AC
Q601 VS2SB709AR/-1 R 2SB709AR AC
Q1001 VS2SD601AR/-1 R 2SD601AR AC
Q1002 VS2SD601AR/-1 R 2SD601AR AC
Q1003 VS2SD601AR/-1 R 2SD601AR AC
Q1004 VS2SK583///-1 R 2SK583 AE
Q1005 VS2SB709AR/-1 R 2SB709AR AC
Q1007 VS2SD601AR/-1 R 2SD601AR AC
Q1008 VS2SD601AR/-1 R 2SD601AR AC
Q1009 VS2SD601AR/-1 R 2SD601AR AC
Q1012 VS2SD601AR/-1 R 2SD601AR AC
Q1013 VS2SD601AR/-1 R 2SD601AR AC
Q1014 VS2SK583///-1 R 2SK583 AE
Q1301 VS2SD601AR/-1 R 2SD601AR AC
Q1302 VS2SD601AR/-1 R 2SD601AR AC
Q1303 VS2SB709AR/-1 R 2SB709AR AC
Q1304 VS2SD601AR/-1 R 2SD601AR AC
Q1305 VS2SD601AR/-1 R 2SD601AR AC
Q1306 VS2SB709AR/-1 R 2SB709AR AC
Q1311 VS2SA1015Y/1E R 2SA1015(Y) AC
Q1312 VS2SD601AR/-1 R 2SD601AR AC
Q1313 VS2SD601AR/-1 R 2SD601AR AC
DIODES
D201 RH-EX0260TAZZ R Zener Diode AC
D202 RH-EX0260TAZZ R Zener Diode AC
D451 RH-EX0631GEZZ R Zener Diode AA
D452 RH-EX0631GEZZ R Zener Diode AA
D453 RH-EX0631GEZZ R Zener Diode AA
D454 RH-EX0631GEZZ R Zener Diode AA
D455 RH-EX0631GEZZ R Zener Diode AA
D456 RH-EX0631GEZZ R Zener Diode AA
D457 RH-EX0631GEZZ R Zener Diode AA
D458 RH-EX0631GEZZ R Zener Diode AA
D459 RH-EX0631GEZZ R Zener Diode AA
D460 RH-EX0631GEZZ R Zener Diode AA
D461 RH-EX0631GEZZ R Zener Diode AA
D462 RH-EX0631GEZZ R Zener Diode AA
D463 RH-EX0631GEZZ R Zener Diode AA
D464 RH-EX0631GEZZ R Zener Diode AA
D465 RH-EX0631GEZZ R Zener Diode AA
D466 RH-EX0619GEZZ R Zener Diode AA
D467 RH-EX0619GEZZ R Zener Diode AA
D468 RH-EX0260TAZZ R Zener Diode AC
D469 RH-EX0260TAZZ R Zener Diode AC
D601 RH-DX0475CEZZ R Diode AB
D602 RH-DX0475CEZZ R Diode AB
D603 RH-DX0475CEZZ R Diode AB
D604 RH-DX0475CEZZ R Diode AB
D607 RH-DX0475CEZZ R Diode AB
D608 RH-EX0604GEZZ R Zener Diode AB
D609 RH-DX0475CEZZ R Diode AB
D615 RH-EX0623GEZZ R Zener Diode AA
D616 RH-DX0475CEZZ R Diode AB
D1001 RH-DX0475CEZZ R Diode AB
D1003 RH-EX1222CEZZ R Zener Diode AE
D1005 RH-EX1222CEZZ R Zener Diode AE
