Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
63
SX68JF100
R1218 VRD-RA2BE152J R 1.5k 1/8W Carbon AA
R1219 VRD-RA2BE472J R 4.7k 1/8W Carbon AA
R1220 VRD-RA2BE103J R 10k 1/8W Carbon AA
R1221 VRD-RA2BE472J R 4.7k 1/8W Carbon AA
R1222 VRD-RA2BE103J R 10k 1/8W Carbon AA
R1223 VRD-RA2BE122J R 1.2k 1/8W Carbon AA
R1224 VRD-RA2BE471J R 470 1/8W Carbon AA
R1225 VRD-RA2BE103J R 10k 1/8W Carbon AA
R1226 VRD-RA2BE472J R 4.7k 1/8W Carbon AA
R1227 VRD-RM2HD101J R 100 1/2W Carbon AA
R1228 VRD-RA2BE101J R 100 1/8W Carbon AB
R1229 VRD-RA2BE103J R 10k 1/8W Carbon AA
R1351 VRD-RA2BE474J R 470k 1/8W Carbon AA
R1352 VRD-RA2BE474J R 470k 1/8W Carbon AA
R1353 VRD-RA2BE123J R 12k 1/8W Carbon AA
R1354 VRD-RA2BE123J R 12k 1/8W Carbon AA
R1355 VRD-RA2BE123J R 12k 1/8W Carbon AA
R1356 VRD-RA2BE223J R 22k 1/8W Carbon AA
R1357 VRD-RA2BE223J R 22k 1/8W Carbon AA
R1358 VRD-RA2BE123J R 12k 1/8W Carbon AA
R1361 VRD-RA2BE103J R 10k 1/8W Carbon AA
R1363 VRD-RA2BE121J R 120 1/8W Carbon AA
R1364 VRD-RA2BE121J R 120 1/8W Carbon AA
R1365 VRD-RA2BE392J R 3.9k 1/8W Carbon AA
R1366 VRD-RA2BE121J R 120 1/8W Carbon AA
R1367 VRD-RA2BE392J R 3.9k 1/8W Carbon AA
R1368 VRD-RA2BE121J R 120 1/8W Carbon AA
SWITCHES
S1200 QSW-K0079GEZZ R CH-Up AB
S1201 QSW-K0079GEZZ R CH-Down AB
S1202 QSW-K0079GEZZ R VOL-Up AB
S1203 QSW-K0079GEZZ R VOL-Down AB
S1204 QSW-K0079GEZZ R Preset/Menu AB
å S1205 QSW-P0588CEZZ R AC Switch AP
MISCELLANEOUS PARTS
J1200 QJAKJ0047CEZZ R Jack, Headphone AD
J1201 QJAKZ0101PEZZ J Jack, AV-3 In AN
P1201 QPLGN0161FJZZ R Plug, 6-pin (AB)
P1202 QPLGN0861CEZZ R Plug, 8-pin (Y) AC
P1203 QPLGN0761CEZZ R Plug, 7-pin (LE) AD
P1204 QPLGN1061CEZZ R Plug, 10-pin (HP) AC
RMC1200
RRMCU0235CEZZ R R/C Receiver AK
SLD1351
PSLDM0237PEFW J Shield AD
LHLDP1056PE00 J Holder AC
PWB-H DUNTKA048WEV1
SUB POWER UNIT
INTEGRATED CIRCUITS
IC2700 VHiMiP0253/-1 R MIP0253SP AM
å IC2701 RH-FX0008GEZZ R PC123FY8 AE
IC2750 VHiSi3051N/-1 R SI3051N AL
TRANSISTORS
Q2750 VS2SC1815GW-1 R 2SC1815GW AB
Q2751 VS2SC1959Y/1E R 2SC1959(Y) AC
DIODES
D2700 RH-DX0083GEZZ R Diode AC
D2750 RH-DX0407CEZZ R Diode AD
D2751 RH-DX0475CEZZ R Diode AB
D2752 RH-EX1329CEZZ R Zener Diode AD
D2754 RH-DX0475CEZZ R Diode AB
å VA2700 RH-VX0048CEZZ R Varistor AE
PACKAGED CIRCUIT
PR2700 RMPTP0085CEZZ R Packaged Circuit AL
COILS AND TRANSFORMER
å L2700 RCiLF0138CEZZ R Coil AQ
å L2701 RCiLF0138CEZZ R Coil AQ
å L2702 RCiLF0138CEZZ R Coil AQ
å T2700 RTRNZ0159PEZZ J Transformer AK
CAPACITORS
å C2700 RC-FZ016SGEZZ R 0.47
AC250V
AK
C2701 VCFYSB2EB224K R 0.22 250V Mylar AD
C2703 RC-KZ0029CEZZ R 0.01
AC250V
Ceramic AC
C2705 VCEA0A2GW475M R 4.7 400V Electrolytic AE
C2706 RC-KZ1022CEZZ R 47p 1kV Ceramic AC
C2707 VCQYTA1HM104J R 0.1 50V Mylar AA
å C2708 RC-FZ016SGEZZ R 0.047
AC250V
AK
C2709 RC-KZ018SCEZZ R 1000p 4kV Ceramic AD
C2750 VCKYPA2HB221K R 220p 500V Ceramic AA
C2751 VCEA0A1CW477M R 470 16V Electrolytic AC
C2752 VCEA0A1AW227M R 220 10V Electrolytic AB
C2753 VCKYPA1HF103Z R 0.01 50V Ceramic AA
RESISTORS
å R2700 VRC-UA2HG275K R 2.7M 1/2W Solid AA
R2701 VRD-RM2HD391J R 390 1/2W Carbon AA
R2702 VRW-KP3HC100J R 10 5W Cement AD
R2750 VRD-RA2BE562J R 5.6k 1/8W Carbon AA
R2751 VRD-RA2BE332J R 3.3k 1/8W Carbon AA
MISCELLANEOUS PARTS
å RY2700 RRLYJ0087CEZZ R Relay AM
å F2700 QFS-C5022CEZZ R Fuse T5A 250V AD
FB2700 RBLN-0037CEZZ R Ferrite Bead AB
FB2750 RBLN-0037CEZZ R Ferrite Bead AB
FH2700 QFSHD1013CEZZ R Fuse Holder AC
FH2701 QFSHD1014CEZZ R Fuse Holder AC
P2700 QPLGN0269GEZZ R Plug, 2-pin (AA) AB
P2701 QPLGN0505CEZZ R Plug, 5-pin (AB) AB
P2702 QPLGN0207CEZZ R Plug, 2-pin (G) AA
P2703 QPLGN0304CEZZ R Plug, 3-pin (AC) AB
P2750 QPLGN0361CEZZ R Plug, 3-pin (XA) AB
LHLDW1037PEZZ J Holder AB
PWB-I DUNTK9863WEV4
NICAM UNIT
INTEGRATED CIRCUITS
IC2300 VHiMSP3410D-1 R MSP3410D BK
IC2301 VHiTDA9808T-1 R TDA9808T AR
IC2302 VHiAN7397K/-1 R AN7397K AX
IC2770 RH-iX3232CEZZ R SSE96G AV
IC2771 VHiBA15218F-1 R BA15218F AD
TRANSISTORS
Q2300 VS2SC2735//1E R 2SC2735 AC
Q2301 VS2SD601AR/-1 R 2SD601AR AC
Q2302 VS2SC2735//1E R 2SC2735 AC
Q2770 VS2SD601AR/-1 R 2SD601AR AC
Q2771 VS2SD601AR/-1 R 2SD601AR AC
Q2772 VS2SD601AR/-1 R 2SD601AR AC
Q2773 VS2SD601AR/-1 R 2SD601AR AC
Q2774 VS2SD601AR/-1 R 2SD601AR AC
Q2775 VS2SD601AR/-1 R 2SD601AR AC
Q2776 VS2SD601AR/-1 R 2SD601AR AC
DIODES
D2300 RH-EX1222CEZZ R Zener Diode AE
D2301 RH-EX1222CEZZ R Zener Diode AE
D2302 RH-DX0475CEZZ R Diode AB
D2303 RH-DX0475CEZZ R Diode AB
PACKAGED CIRCUIT
X2301 RCRSB0249GEZZ R Crystal AF
COILS AND TRANSFORMER
L2300 VP-DF120K0000 R Peaking 12µH AB
