Sharp UA-KIL80E

EN-6
PART NAMES
OPERATION PANEL
FRONT DISPLAY
15
14
138 4561012
71113 2
19 17
21 20 18
16
9
Directly under
a light fixture.
In shadow
When the Light Control
is set to “Auto”, Front
Display and Cleanliness
Indicator will automatically
switch ON or OFF based
on room brightness.
(Page 12, 13)
NOTE
Detection range of Light sensor
Do not install the product in the following places.
The Light Sensor may not sense correctly.
LIGHT SENSOR
*The illustration in this instruction manual is UA-KIL80E.
